描述
ABB Panel Bus Adapter Kit FDPI-02是一款用于工业自动化领域的面板总线适配器套件，以下是其产品详情：
基本信息
品牌：ABB
型号：FDPI-02
产品编号：3AUA0000108650
产地：瑞典
尺寸：95mm×35mm×26mm
重量：约0.07kg
防护等级：IP20
技术参数
通信协议支持：Profibus DP、CANopen、Modbus RTU，兼容RS-485面板总线。
连接方式：1×RJ-11（连接控制单元）、2×RJ-45（支持菊花链总线，用于PC或控制面板级联）。
终端配置：内置总线端接开关，支持菊花链末端信号反射抑制。
兼容性：适配ZCU-xx/BCU-xx/UCU-xx控制单元，支持ACS-AP-I/W系列控制面板。
诊断功能：实时显示驱动参数（速度、扭矩、电流）、故障代码及诊断信息。
产品特点
灵活的总线集成：通过RS-485实现多个驱动器的菊花链连接，便于系统扩展和集成。
即插即用设计：使用RJ-11和RJ-45连接器，可轻松安装在控制单元的插槽中。
信号完整性高：内置总线端接开关，可有效防止信号反射，确保通信的稳定性。
支持模块扩展：可在顶部堆叠F型选件模块，以扩展功能。
应用场景
驱动网络：将ABB驱动器（如ACS系列）连接到控制面板，进行参数调整和监控。
工业诊断：通过Drive Studio等工具，实现基于PC的监控和诊断。
The ABB Panel Bus Adapter Kit FDPI-02 is a panel bus adapter kit for industrial automation.Below are its product details:
Basic Information
Brand:ABB
Model:FDPI-02
Product Number:3AUA0000108650
Origin:Sweden
Dimensions:95mm×35mm×26mm
Weight:Approx.0.07kg
Protection Rating:IP20
Technical Specifications
Communication Protocol Support:Profibus DP,CANopen,Modbus RTU,compatible with RS-485 panel bus.
Connection Methods:1×RJ-11(for connecting control units),2×RJ-45(supports daisy-chain bus for PC or control panel cascading).
Termination Configuration:Built-in bus termination switch,supports daisy-chain end signal reflection suppression.
Compatibility:Adapts to ZCU-xx/BCU-xx/UCU-xx control units,supports ACS-AP-I/W series control panels.
Diagnostic Functions:Real-time display of drive parameters(speed,torque,current),fault codes,and diagnostic information.
Product Features:
Flexible Bus Integration:Daisy-chaining of multiple drives via RS-485 facilitates system expansion and integration.
Plug-and-Play Design:Easily installed in control unit slots using RJ-11 and RJ-45 connectors.
High Signal Integrity:Built-in bus termination switch effectively prevents signal reflections,ensuring stable communication.
Module Expansion Support:F-type option modules can be stacked on top to expand functionality.
Application Scenarios:
Drive Networking:Connect ABB drives(such as the ACS series)to control panels for parameter adjustment and monitoring.
Industrial Diagnostics:Enable PC-based monitoring and diagnostics using tools such as Drive Studio.
