描述
ABB PCO012是一款PROFIBUS DP连接器，以下是其产品详情：
基本信息
品牌：ABB
型号：PCO012
产品编号：3BDZ000398R1
备用型号：3BDZ000372R1
连接器类型：9针D型SUB-D连接器
通信协议：PROFIBUS DP V1/V2
电源：DC 24V
产地：瑞典
技术参数
数据传输速率：最高12Mbps（铜缆，传输距离可达100m）；1.5Mbps时可达400m；9.6kbps时可达1200m
总线终端电阻：集成150Ω±15%金属膜电阻，可通过滑动开关选择
信号反射：在12Mbps时，≤-20dB（在终端点测量），确保每10⁹位数据传输中错误≤1个
电气保护：ESD保护，符合IEC 61000-4-2标准，空气放电±4kV，接触放电±2kV；浪涌保护1kV（线对线，符合IEC 61000-4-5标准）；共模噪声抑制≥65dB（在1MHz时）；绝缘电阻≥200MΩ（在500V DC，20℃时）
工作温度范围：-20℃至+60℃
存储温度范围：-40℃至+85℃
防护等级：IP40
产品特点
连接可靠：采用9针D型SUB-D连接器，确保连接牢固，可有效抵抗振动和冲击，适合在恶劣的工业环境中使用。
抗干扰能力强：具有良好的电磁兼容性，能有效抑制电磁干扰（EMI）和射频干扰（RFI），保证信号传输的稳定性和准确性。
易于安装：配备可切换的总线终端电阻，通过滑动开关即可轻松设置，简化了安装过程，减少了布线复杂度。
兼容性好：支持PROFIBUS DP V1/V2协议，与ABB的S800 I/O模块、AC500 PLC、ACS驱动器等设备以及其他第三方PROFIBUS兼容设备均可无缝连接。
The ABB PCO012 is a PROFIBUS DP connector.Below are its product details:
Basic Information
Brand:ABB
Model:PCO012
Product Number:3BDZ000398R1
Spare Model:3BDZ000372R1
Connector Type:9-pin D-type SUB-D connector
Communication Protocol:PROFIBUS DP V1/V2
Power Supply:DC 24V
Origin:Sweden
Technical Specifications
Data Transmission Rate:Up to 12Mbps(copper cable,transmission distance up to 100m);up to 400m at 1.5Mbps;up to 1200m at 9.6kbps
Bus Termination Resistor:Integrated 150Ω±15%metal film resistor,selectable via a slide switch
Signal Reflection:≤-20dB at 12Mbps(measured at the termination point),ensuring≤1 error per 10⁹bits of data transmission
Electrical Protection:ESD protection,compliant with IEC Standard 61000-4-2:Air discharge±4kV,contact discharge±2kV;Surge protection 1kV(wire-to-wire,conforming to IEC 61000-4-5);Common-mode noise suppression≥65dB(at 1MHz);Insulation resistance≥200MΩ(at 500V DC,20℃)
Operating temperature range:-20℃to+60℃
Storage temperature range:-40℃to+85℃
Protection rating:IP40
Product Features
Reliable connection:Employs a 9-pin D-type SUB-D connector,ensuring a secure connection and effectively resisting vibration and shock,suitable for use in harsh industrial environments.
Strong anti-interference capability:Excellent electromagnetic compatibility,effectively suppressing electromagnetic interference(EMI)and radio frequency interference(RFI),ensuring the stability and accuracy of signal transmission.
Easy installation:Equipped with a switchable bus terminating resistor,easily set via a slide switch,simplifying the installation process and reducing wiring complexity.
Excellent compatibility:Supports PROFIBUS DP V1/V2 protocol,and can be seamlessly connected with ABB’s S800 I/O modules,AC500 PLC,ACS drives and other third-party PROFIBUS compatible devices.
