描述
ABB PDB-02 3HNA023093-001是工业机器人控制柜的核心电源模块，主要用于电源分配、温度信号处理及系统保护。以下是其详细信息整理：
一、产品概述
类型：电源分配板/热电偶/mV输入模块（功能集成设计）
品牌：ABB（瑞士原产，多由福建、广东经销商代理）
核心功能：
-为机器人控制柜提供稳定电源分配（24V输入，电流100-400A）；
-接收热电偶或毫伏信号，转换为数字信号用于温度监测；
-支持信号放大、滤波及数字化处理，提升测量精度。
二、技术参数
项目参数
尺寸/重量435×120×181mm，净重5.9kg（与框架尺寸匹配）
电源输入24V DC（标准工业电压）
适用设备ABB喷涂机器人控制柜（PDB-02型）、工业自动化生产线
信号输入热电偶（支持多种金属组合）、毫伏信号（±1mV精度）
输出接口数字信号输出（兼容PLC、SCADA系统）
三、功能特性
电源管理：
-分配电力至机器人执行机构（如电机、传感器）；
-过载保护机制，防止电压波动损坏设备。
温度监测：
-通过热电偶测量温度，转换为热电动势信号；
-支持冷端温度补偿，减少测量误差。
抗干扰设计：
-内置滤波电路，抑制变频器等设备的电磁干扰；
-推荐加装隔离模块（如TA3012）增强稳定性。
四、应用领域
工业机器人：
-喷涂、焊接、搬运等场景的电源与信号控制；
-适配ABB PDB-02控制柜，保障精准作业。
自动化系统：
-制造设备电力分配、物流分拣线监控；
-化工、冶金行业的高温环境监测。
ABB PDB-02 3HNA023093-001 is the core power module of industrial robot control cabinet,mainly used for power distribution,temperature signal processing and system protection.The following is a detailed summary of its information:
1.Product Overview
Type:Power distribution board/thermocouple/mV input module(functional integrated design)
Brand:ABB(original from Switzerland,mostly represented by Fujian and Guangdong dealers)
Core functions:
-Provide stable power distribution for robot control cabinet(24V input,current 100-400A);
-Receive thermocouple or millivolt signals,converted into digital signals for temperature monitoring;
-Supports signal amplification,filtering and digitization processing to improve measurement accuracy.
2.Technical parameters
Project Parameters
Dimensions/weight:435×120×181mm,net weight:5.9kg(matches frame size)
Power input 24V DC(standard industrial voltage)
Applicable equipment ABB spray robot control cabinet(PDB-02 type),industrial automation production line
Signal input Thermocouple(supports multiple metal combinations),millivolt signal(±1mV accuracy)
Output interface Digital signal output(compatible with PLC and SCADA systems)
3.Functional characteristics
Power Management:
-Distribute power to robot actuators(such as motors,sensors);
-Overload protection mechanism to prevent voltage fluctuations from damaging the equipment.
Temperature monitoring:
-Measure the temperature by a thermocouple and convert it to a thermoelectric force signal;
-Supports cold junction temperature compensation to reduce measurement errors.
Anti-interference design:
-Built-in filtering circuit to suppress electromagnetic interference from inverters and other equipment;
-It is recommended to install isolation modules(such as TA3012)to enhance stability.
IV.Application fields
Industrial Robots:
-Power and signal control in spraying,welding,handling and other scenarios;
-Adapted to ABB PDB-02 control cabinet to ensure accurate operation.
Automation system:
-Monitoring of power distribution and logistics sorting line for manufacturing equipment;
-High temperature environment monitoring in the chemical and metallurgy industries.
