描述
ABB PDP800是工业自动化领域的多功能控制模块，主要用于人机交互（HMI）、PROFIBUS通信接口及电力系统控制。以下是其详细信息整理：
一、产品概述
类型：模块化控制设备（涵盖HMI触摸屏、PROFIBUS主站模块等多款型号）
品牌：ABB（欧美原产，福建、北京等地有经销商仓储）
核心功能：
-HMI交互：高分辨率触摸屏，支持多协议通信；
-工业通信：PROFIBUS DP接口，实现设备无缝集成；
-数据处理：支持1ms级事件时间戳与冗余配置。
二、技术参数
项目参数
尺寸/重量243.84×170.18×73.66mm，约1.2kg（标准型号）
电源输入220V AC（标准工业电压）
通信接口PROFIBUS DP（V0/V1/V2）、以太网、USB等
工作环境温度：-30°C～+70°C；湿度：95%（部分型号可达IP65防护）
数据容量程序存储2MB，运行数据1MB（HMI型号）
三、功能特性
HMI功能（Panel 800系列）：
-显示性能：TFT/LED高分辨率屏幕（7–21.5英寸可选），支持矢量图形与多语言界面；
-设计工具：Panel Builder软件，集成模板库加速工程开发。
PROFIBUS通信（SD系列）：
-协议支持：DP V0/V1/V2，兼容PA设备；
-扩展能力：光纤传输最远15km，冗余配置提升系统可靠性；
-应用场景：集成智能变送器、涡轮机保护模块（TP800）等。
通用优势：
-兼容性：支持ABB UNITROL、S800 I/O等设备；
-诊断功能：实时监测设备状态，支持故障报警。
四、应用领域
电力与水利：发电厂监控、变电站自动化；
工业控制：
-制造业PLC联网（如Foxboro I/A Series）；
-冶金、化工设备保护（阀门定位VP800）；
能源管理：风电场远程控制、光伏并网调节。
ABB PDP800 is a multifunctional control module in the field of industrial automation,mainly used for human-computer interaction(HMI),PROFIBUS communication interface and power system control.The following is a detailed summary of its information:
1.Product Overview
Type:Modular control equipment(covering many models such as HMI touch screen,PROFIBUS main station module,etc.)
Brand:ABB(originated in Europe and the United States,with distributors stored in Fujian,Beijing and other places)
Core functions:
-HMI interaction:high-resolution touch screen,supporting multi-protocol communication;
-Industrial communication:PROFIBUS DP interface,achieving seamless equipment integration;
-Data processing:Supports 1ms-level event timestamps and redundant configurations.
2.Technical parameters
Project Parameters
Dimensions/weights:243.84×170.18×73.66mm,approximately 1.2kg(standard model)
Power input 220V AC(standard industrial voltage)
Communication interface PROFIBUS DP(V0/V1/V2),Ethernet,USB,etc.
Working environment Temperature:-30°C~+70°C;Humidity:95%(some models can reach IP65 protection)
Data capacity:2MB of program storage,1MB of running data(HMI model)
3.Functional characteristics
HMI function(Panel 800 series):
-Display performance:TFT/LED high-resolution screen(optional 7–21.5 inches),supporting vector graphics and multilingual interfaces;
-Design tools:Panel Builder software,integrated template library to accelerate engineering development.
PROFIBUS Communications(SD Series):
-Protocol support:DP V0/V1/V2,compatible with PA devices;
-Expansion capability:fiber transmission is up to 15km,and redundant configuration improves system reliability;
-Application scenarios:Integrated intelligent transmitter,turbine protection module(TP800),etc.
General Advantages:
-Compatibility:Supports ABB UNITROL,S800 I/O and other devices;
-Diagnostic function:Real-time monitoring of equipment status,supporting fault alarms.
IV.Application fields
Electricity and water conservancy:power plant monitoring,substation automation;
Industrial Control:
-Manufacturing PLC networking(such as Foxboro I/A Series);
-Metallurgical and chemical equipment protection(valve positioning VP800);
Energy management:remote control of wind farms,photovoltaic grid-connected regulation.
