描述
ABB PE1364B是一款Modbus TCP/DDCS协议转换器，主要用于工业自动化控制系统中实现不同协议之间的数据交换。以下是其产品详情：
基本信息
品牌：ABB
型号：PE1364B
产品类型：协议转换器
输入电压：24V DC
技术参数
协议兼容性：支持Modbus TCP和DDCS协议。
通信速度：最高可达1 Mbps。
数据传输容量：最多可连接100台设备。
工作温度范围：-20°C至+70°C。
存储温度范围：-40°C至+85°C。
连接器类型：Modbus TCP连接采用RJ45以太网连接器，服务端口RS232采用9针D型Sub连接器，模块总线（DDCS）采用光纤连接器。
功耗：24V DC时电流消耗为170mA。
产品特点
兼容性强：能与ABB的ACS系列驱动器以及各种第三方Modbus设备兼容，实现不同协议设备之间的无缝通信。
数据传输高效：具备高速Modbus TCP能力，可实现实时数据交换，满足复杂自动化环境下对数据传输及时性的要求。
保护功能完善：具有过载、过流、短路和热保护功能，确保在各种异常情况下设备的安全运行。
设计紧凑：尺寸小巧，如120mm x 80mm x 40mm的规格，便于安装在各种工业环境中，节省安装空间。
适应范围广：宽温度工作范围和多种保护机制，使其能在恶劣的工业环境中保持稳定的性能。
The ABB PE1364B is a Modbus TCP/DDCS protocol converter,primarily used in industrial automation control systems to enable data exchange between different protocols.Below are its product details:
Basic Information
Brand:ABB
Model:PE1364B
Product Type:Protocol Converter
Input Voltage:24V DC
Technical Specifications
Protocol Compatibility:Supports Modbus TCP and DDCS protocols.
Communication Speed:Up to 1 Mbps.
Data Transfer Capacity:Supports up to 100 devices.
Operating Temperature Range:-20°C to+70°C.
Storage Temperature Range:-40°C to+85°C.
Connector Type:Modbus TCP connection uses an RJ45 Ethernet connector;RS232 service port uses a 9-pin D-type Sub connector;DDCS uses a fiber optic connector.
Power Consumption:170mA at 24V DC.
Product Features
High Compatibility:Compatible with ABB’s ACS series drives and various third-party Modbus devices,enabling seamless communication between devices using different protocols.
High-Efficiency Data Transmission:Equipped with high-speed Modbus TCP capability,enabling real-time data exchange and meeting the timeliness requirements of data transmission in complex automated environments.
Comprehensive Protection Functions:Features overload,overcurrent,short-circuit,and thermal protection functions to ensure safe operation of the device under various abnormal conditions.
Compact Design:Compact size,such as 120mm x 80mm x 40mm,facilitates installation in various industrial environments,saving installation space.
Wide Adaptability:Wide operating temperature range and multiple protection mechanisms enable it to maintain stable performance in harsh industrial environments.
