一、核心功能与定位
类型：工业级DCS（分布式控制系统）电源模块，专为高可靠性工业自动化场景设计，提供稳定电力供应与冗余保护。
核心功能：
双路隔离输出：支持12V DC和36V DC输出，满足不同设备的供电需求，减少共地干扰。
宽输入电压范围：兼容175-264V AC输入，适应复杂电网环境。
过压保护：内置输入过压保护机制，防止电压异常损坏设备。
高隔离电压：输入与输出隔离电压达4500V AC，保障电气安全。
EMC性能：抗干扰能力强，适用于电磁环境复杂的工业现场。
二、技术参数
输入特性
电压范围：175-264V AC。
过压保护阈值：未明确数值，但支持自动切断异常输入。
输出特性
双路隔离输出：12V DC（通道1）与36V DC（通道2）。
输出功率：未明确数值，但适用于高功率设备（如电梯门机驱动、电机控制等）。
环境适应性
工作温度：0°C至70°C（部分型号支持更宽温域）。
湿度范围：5%至95%（非冷凝环境）。
防护等级：未明确，但符合工业级防护标准。
安全与认证
隔离电压：4500V AC。
认证标准：符合欧盟CE、RoHS等工业安全规范。
三、核心应用场景
工业自动化系统
为PLC、传感器、I/O模块等提供稳定电源，保障控制系统可靠性。
电梯与屏蔽门系统
门机电机驱动电源（如DC110V/DC48V）、安全回路供电（DC24V）。
电力与过程控制
电厂、水处理等大型DCS系统的冗余电源模块。
通信与医疗设备
路由器、通信基站、医疗成像设备的电力支持。
四、技术优势
双路隔离设计：降低多电压设备共地干扰风险，提升系统稳定性。
宽输入兼容性：适应全球不同电网标准，减少电源适配需求。
高可靠性：通过ABB TVOC-2电弧闪光保护技术，故障清除时间小于50毫秒。
模块化集成：支持与ABB Symphony INFi 90等工业网络无缝衔接，扩展性强。
1.Core functions and positioning
Type:Industrial-grade DCS(Distributed Control System)power module,specially designed for high-reliability industrial automation scenarios,providing stable power supply and redundancy protection.
Core functions:
Dual isolated output:supports 12V DC and 36V DC outputs,meeting the power supply needs of different devices and reducing common ground interference.
Wide input voltage range:compatible with 175-264V AC input,adapted to complex grid environments.
Overvoltage protection:Built-in input overvoltage protection mechanism to prevent voltage abnormality from damaging the equipment.
High isolation voltage:The input and output isolation voltage reaches 4500V AC,ensuring electrical safety.
EMC performance:Strong anti-interference ability,suitable for industrial sites with complex electromagnetic environments.
2.Technical parameters
Input Features
Voltage range:175-264V AC.
Overvoltage protection threshold:The value is not clear,but it supports automatic cutoff of abnormal input.
Output Characteristics
Dual Isolated Outputs:12V DC(Channel 1)and 36V DC(Channel 2).
Output power:The value is not specified,but it is suitable for high-power equipment(such as elevator door drivers,motor control,etc.).
Environmental adaptability
Operating temperature:0°C to 70°C(some models support wider temperature range).
Humidity range:5%to 95%(non-condensing environment).
Protection level:Not clear,but meets industrial-grade protection standards.
Safety and certification
Isolation voltage:4500V AC.
Certification standards:Comply with EU CE,RoHS and other industrial safety specifications.
3.Core application scenarios
Industrial automation system
Provides stable power supply for PLC,sensors,I/O modules,etc.to ensure the reliability of the control system.
Elevator and shielded door system
Door motor drive power supply(such as DC110V/DC48V),safety loop power supply(DC24V).
Power and process control
Redundant power modules for large DCS systems such as power plants and water treatment.
Communications and medical equipment
Power support for routers,communication base stations,and medical imaging equipment.
4.Technical advantages
Dual-channel isolation design:reduces the risk of common ground interference of multi-voltage equipment and improves system stability.
Wide input compatibility:adapts to different global grid standards and reduces power adaptation needs.
High reliability:With ABB TVOC-2 arc flash protection technology,the fault clearance time is less than 50 milliseconds.
Modular integration:supports seamless connection with industrial networks such as ABB Symphony INFi 90,and is highly scalable.
