描述
ABB PM858K02是一款AC800M系列的控制器单元，订货编号为3BSE082896R1。以下是其产品详情：
基本信息
输入电压：24VDC（范围19.2-30VDC）
功耗：+24V典型值/最大值为210mA/360mA，功率典型值为5.1W（最大8.6W）
内置电池：锂电池，3.6V
防护等级：IP20
性能参数
处理器类型：MPC866
时钟频率：33MHz
布尔运算速度：1000个布尔运算/0.36ms
内存：16MB RAM，其中可供应用程序使用的为7.147MB，用于存储固件的Flash PROM为4MB
以太网接口：2个（RJ45接口），用于连接控制网络
串行接口：2个RS-232C接口（RJ45接口），COM3是带有调制解调器控制信号的端口，COM4为隔离端口，用于连接配置工具
I/O容量：中央处理器在7个光学Modulebus上的I/O容量最多96个（单个PM866）或84个（冗余PM866）I/O模块。
应用程序与任务：每个控制器最多32个应用程序，每个应用程序最多64个程序、128个图表，每个控制器最多32个任务，不同循环时间的数量为32个，应用程序周期时间可低至1ms。
套件内容
2个PM858 CPU
2个TP830底板
2个TB807模块总线终端器
1个TK850 CEX总线扩展电缆
1个TK851 RCU链接电缆
2个内存备份电池（4943013-6），每个控制器1个
功能特点
可靠性高：具备完整的EMC认证，还通过了ISA Secure认证，确保在各种工业环境下稳定运行，且故障诊断程序简单。
支持冗余：支持CPU冗余，包括CPU、CEX总线、通信接口和S800 I/O，切换时间最大为10ms，提高了系统的可用性。
易于配置：可使用800xA Control Builder进行配置。
模块化设计：允许逐步扩展，适应不同规模的工业自动化需求。
通信能力强：内置冗余以太网通信端口，支持MMS、IAC等多种通信协议，推荐的控制网络骨干网为100Mbit/s交换以太网，还可通过扩展模块支持Profibus DP、FF、Modbus等多种现场总线协议。
The ABB PM858K02 is a controller unit in the AC800M series,with order number 3BSE082896R1.Here are the product details:
Basic Information
Input Voltage:24VDC(range 19.2-30VDC)
Power Consumption:+24V typical/maximum 210mA/360mA,typical power consumption 5.1W(maximum 8.6W)
Built-in Battery:Lithium battery,3.6V
Protection Rating:IP20
Performance Parameters
Processor Type:MPC866
Clock Frequency:33MHz
Boolean Operation Speed:1000 Boolean operations/0.36ms
Memory:16MB RAM,of which 7.147MB is available for application use,and 4MB is Flash PROM for firmware storage
Ethernet Interfaces:2(RJ45 interfaces)for connecting to the control network
Serial Interfaces:2 RS-232C interfaces(RJ45 interfaces),COM3 is a port with modem control signals,COM4 is an isolated port for connecting configuration tools
I/O Capacity:CPU I/O on 7 optical Modulebuses Capacity up to 96(single PM866)or 84(redundant PM866)I/O modules.
Applications and Tasks:Up to 32 applications per controller,up to 64 programs and 128 graphs per application,up to 32 tasks per controller,32 different cycle times,application cycle time as low as 1ms.
Kit Contents:
2 PM858 CPUs
2 TP830 baseboards
2 TB807 module bus terminators
1 TK850 CEX bus extension cable
1 TK851 RCU link cable
2 memory backup batteries(4943013-6),1 per controller
Features:High reliability:Full EMC certification and ISA Secure certification ensure stable operation in various industrial environments,with simple fault diagnosis procedures.
Redundancy Support:Supports CPU redundancy,including CPU,CEX bus,communication interfaces,and S800 I/O,with a maximum switching time of 10ms,improving system availability.
Easy Configuration:Can be configured using the 800xA Control Builder.
Modular Design:Allows for gradual expansion to adapt to industrial automation needs of different scales.
Strong Communication Capabilities:Built-in redundant Ethernet communication ports,supporting multiple communication protocols such as MMS and IAC.The recommended control network backbone is 100Mbit/s switched Ethernet,and it can also support multiple fieldbus protocols such as Profibus DP,FF,and Modbus through expansion modules.
