描述
ABB PM860AK01 3BSE066495R1是一款高性能的处理器单元，适用于AC 800M/800xA分布式控制系统，以下是其产品详情：
基本信息
制造商：ABB
电源：24VDC（范围19.2-30VDC），典型电流180mA，最大电流300mA，功率约7.2W
安装方式：通过DIN导轨安装
尺寸：160×200×140mm
重量：1.1kg
防护等级：IP20
认证：EMC认证，UL、CE、DNV-GL、ABS等认证
性能参数
处理器：MPC860，48MHz
内存：Flash≥2MB，RAM 16MB（约10.35MB可供应用程序使用）
执行速度：每1000次布尔运算0.23ms
通信端口：2个以太网端口（10Mbit/s），2个RS-232C端口，其中COM3为非隔离端口，COM4为隔离端口
I/O总线支持：模块总线上最多支持96个模块，CEX总线上最多支持12个模块
功能特点
模块化架构：易于在现场进行扩展，具有灵活的I/O容量。
强大的连接性：双以太网和RS-232C端口增强了网络弹性。
故障诊断：配备LED指示灯和初始化按钮，便于快速进行故障排除。
实时性能：0.23ms的逻辑周期支持快速控制回路。
应用场景
适用于石油天然气、化工、电力等行业的过程自动化系统中的中央控制。
可用于分布式撬装单元的远程混合控制。
也可在系统升级或现场改造时作为替换单元。
The ABB PM860AK01 3BSE066495R1 is a high-performance processor unit suitable for AC 800M/800xA distributed control systems.Below are its product details:
Basic Information
Manufacturer:ABB
Power Supply:24VDC(range 19.2-30VDC),typical current 180mA,maximum current 300mA,power consumption approx.7.2W
Mounting Method:DIN rail mounting
Dimensions:160×200×140mm
Weight:1.1kg
Protection Rating:IP20
Certifications:EMC certified,UL,CE,DNV-GL,ABS,etc.
Performance Parameters
Processor:MPC860,48MHz
Memory:Flash≥2MB,RAM 16MB(approx.10.35MB available for application use)
Execution Speed:0.23ms per 1000 Boolean operations
Communication Ports:2 Ethernet ports(10Mbit/s),2…RS-232C ports,with COM3 being a non-isolated port and COM4 an isolated port.
I/O Bus Support:Up to 96 modules are supported on the module bus,and up to 12 modules on the CEX bus.
Features:
Modular Architecture:Easy to expand in the field,with flexible I/O capacity.
Strong Connectivity:Dual Ethernet and RS-232C ports enhance network resilience.
Fault Diagnosis:Equipped with LED indicators and an initialization button for quick troubleshooting.
Real-Time Performance:A 0.23ms logic cycle supports fast control loops.
Application Scenarios:Suitable for central control in process automation systems in industries such as oil and gas,chemical,and power.
Can be used for remote hybrid control of distributed skid-mounted units.
Can also be used as a replacement unit during system upgrades or field modifications.
