描述
ABB PPC380AE01是一款高性能的工业控制器模块，属于ABB PPC系列。以下是其详细产品详情：
硬件参数
处理器：采用32位RISC处理器或Intel Core i7-6700TE等高性能处理器。
内存：256KB RAM，512KB Flash。
输入电压：AC 90-264V或110-240V AC。
输出电压：DC 24V。
通信接口：支持RS-232、RS-485、CAN、以太网等。
I/O接口：32个数字I/O，16个模拟I/O。
工作温度范围：-20℃至+60℃。
存储温度范围：-40℃至+85℃。
外形尺寸：135mm x 93mm x 58mm。
重量：约0.4kg。
产品特点
控制功能集成：控制和驱动功能集成一体，内部集成PLC控制器，可通过梯形图编程使PLC和伺服驱动器形成有机整体。
多种控制模式：支持位置控制模式、速度控制模式和电流（转矩）控制模式，并支持各种模式之间的实时切换，还内置S曲线和T曲线轨迹规划功能。
通信协议丰富：支持USB、RS232、RS485和CAN总线通讯，以及MOTEC、MODBUS和CANOPEN协议。
保护功能齐全：具有STO、温度、过流、过压、欠压保护、位置超差、速度超差、I2T电流限制等功能。
扩展性强：支持多个扩展槽和模块化设计，可与其他PPC系列模块配合使用，满足不同应用需求。
应用领域
工业自动化：可用于变频器控制、过程控制、机器人控制和楼宇自动化等。
能源管理：能够精确监控和控制能源消耗。
制造业：适用于自动化生产线、机械控制等场景。
电力行业：可用于电站和电力系统的智能控制和调节。
石油化工：可对炼油、化工生产过程中的温度、压力等参数进行监控与控制。
The ABB PPC380AE01 is a high-performance industrial controller module,part of the ABB PPC series.The following are detailed product details:
Hardware Specifications
Processor:32-bit RISC processor or high-performance processor such as the Intel Core i7-6700TE.
Memory:256KB RAM,512KB Flash.
Input Voltage:AC 90-264V or AC 110-240V.
Output Voltage:DC 24V.
Communication Interfaces:Supports RS-232,RS-485,CAN,Ethernet,etc.
I/O Interfaces:32 digital I/O ports,16 analog I/O ports.
Operating Temperature Range:-20°C to+60°C.
Storage Temperature Range:-40°C to+85°C.
Dimensions:135mm x 93mm x 58mm.
Weight:Approximately 0.4kg.Product Features
Integrated Control Functions:Control and drive functions are integrated into one,with an internal PLC controller.Ladder diagram programming allows the PLC and servo drive to form an organic whole.
Multiple Control Modes:Supports position control,speed control,and current(torque)control modes,with real-time switching between these modes.It also features built-in S-curve and T-curve trajectory planning.
Comprehensive Communication Protocols:Supports USB,RS232,RS485,and CAN bus communications,as well as MOTEC,MODBUS,and CANOPEN protocols.
Comprehensive Protection Functions:Features STO,temperature,overcurrent,overvoltage,undervoltage protection,position tolerance,speed tolerance,and I²T current limiting.
Strong Scalability:Supports multiple expansion slots and a modular design,allowing integration with other PPC series modules to meet diverse application needs.
Applications:
Industrial Automation:Suitable for inverter control,process control,robotic control,and building automation.
Energy Management:Accurately monitors and controls energy consumption.Manufacturing:Suitable for scenarios such as automated production lines and machine control.
Power Industry:Suitable for intelligent control and regulation of power plants and power systems.
Petrochemical:Suitable for monitoring and controlling parameters such as temperature and pressure during refining and chemical production.
