描述
ABB PPD103B01是一款高性能过程控制模块，属于AC 800PEC控制系统的核心组件。以下是其产品详情：
基本信息
产品类型：过程控制模块
输入电压：24VDC±10%
物理尺寸：150×100×30mm
重量：0.25kg
防护等级：IP20
认证标准：CE、RoHS
技术参数
数字I/O：16路输入/16路输出（24VDC）
模拟I/O：4路输入/4路输出（0-10V/4-20mA）
通信协议：Modbus RTU、Profibus DP
工作温度：-20°C至+60°C
存储温度：-40°C至+85°C
产品特点
显示与操作：配备3英寸TFT显示屏，支持中文菜单与图形化操作，简化现场参数调整流程。
响应速度：10ms的信号更新速率，可实时捕捉设备状态变化，适用于需要快速联锁的场景。
冗余设计：支持双电源输入（24VDC±10%），确保在单电源故障时仍能维持运行。
精度与控制：14位分辨率与±0.15%的测量精度，可精确调节电机励磁电流，降低能耗约15%。
故障诊断：实时监测模块健康状态，通过LED指示灯与Modbus寄存器输出故障代码，缩短平均修复时间（MTTR）至30分钟内。
安全合规：符合IEC 61508 SIL 2标准，适用于核电站辅助系统等安全关键型应用。
通信架构：Anybus插槽支持定制化协议转换，可连接HMI、SCADA等上层系统，实现数据透明化。
热插拔功能：支持在线更换模块，配合AC 800PEC的组态工具，可在5分钟内完成配置与验证。
应用领域
广泛应用于石油化工、电力能源、食品饮料、冶金、水利水电、船舶工业等领域，可用于炼油厂分馏塔温度控制、化工厂反应釜压力监测、风电变流器振动传感器信号采集、轧机主电机励磁控制等场景。
.The ABB PPD103B01 is a high-performance process control module,a core component of the AC 800PEC control system.Here are its product details:
Basic Information
Product Type:Process Control Module
Input Voltage:24VDC±10%
Dimensions:150×100×30mm
Weight:0.25kg
Protection Level:IP20
Certifications:CE,RoHS
Technical Specifications
Digital I/O:16 inputs/16 outputs(24VDC)
Analog I/O:4 inputs/4 outputs(0-10V/4-20mA)
Communication Protocols:Modbus RTU,Profibus DP
Operating Temperature:-20°C to+60°C
Storage Temperature:-40°C to+85°C
Product Features
Display and Operation:Equipped with a 3-inch TFT display,supporting Chinese menus and graphical operation,simplifying on-site parameter adjustment.
Response Speed:10ms signal update rate for real-time capture of device status changes,suitable for applications requiring fast interlocking.
Redundancy Design:Supports dual power input(24VDC±10%),ensuring continued operation even with a single power supply failure.
Accuracy and Control:14-bit resolution and±0.15%measurement accuracy for precise motor excitation current control,reducing energy consumption by approximately 15%.
Fault Diagnosis:Real-time monitoring of module health status,with LED indicators and Modbus register output of fault codes,reducing mean time to repair(MTTR)to within 30 minutes.
Safety Compliance:Compliant with IEC 61508 SIL 2 standard,suitable for safety-critical applications such as nuclear power plant auxiliary systems.
Communication Architecture:Anybus slot supports customized protocol conversion,connecting to HMI,SCADA,and other higher-level systems for data transparency.
Hot-Swappable:Supports online module replacement;with the AC 800PEC configuration tool,configuration and verification can be completed within 5 minutes.Application Areas
Widely used in industries such as petrochemicals,power generation,food and beverage,metallurgy,hydropower,and shipbuilding,it can be used for applications such as temperature control in distillation towers of oil refineries,pressure monitoring in chemical reactor vessels,vibration sensor signal acquisition for wind power converters,and excitation control of main motors in rolling mills.
