描述
ABB Robotics DSQC 223（YB560103-BD）是一款数字输入/输出模块，以下是其产品详情：
基本信息：
品牌：ABB
型号：DSQC 223
产品ID：YB560103-BD
原产国：瑞典
重量：约0.28kg
技术参数：
工作电压：24V DC
输入输出通道：通常支持16路数字输入和16路数字输出
输出特性：输出具有反极性保护和24V DC强制供电保护功能。部分输出通道可通过配置分配给内部高速计数器，如端子46（A62,00），当计数器工作在模式1或2（向上计数）时，该输出仅用于计数器，若要作为普通数字输出，则需确保高速计数器未配置为模式1或2。
物理特性：
尺寸：约为180mm×125.5mm×21.5mm（仅供参考，具体可能因生产批次略有差异）
外观：一般为黑色电路板，带有2个64针连接器，2组16个黄色LED指示灯和1个红色LED指示灯。
功能特点：
高可靠性：采用坚固的设计和高质量的电子元件，具有强抗干扰能力，能在恶劣的工业环境中稳定工作。
易于集成：支持多种工业通信协议，可方便地集成到ABB机器人控制系统以及其他自动化控制系统中，实现设备之间的信号交互和协同工作。
应用领域：
广泛应用于汽车制造、电子制造、机械加工、石油化工等行业，可用于机器人系统中各种设备的状态监测与控制，如控制机器人的夹具开合、检测工件的到位情况等。
The ABB Robotics DSQC 223(YB560103-BD)is a digital input/output module.The following are its product details:
Basic Information:
Brand:ABB
Model:DSQC 223
Product ID:YB560103-BD
Country of Origin:Sweden
Weight:Approximately 0.28 kg
Technical Parameters:
Operating Voltage:24V DC
Input and Output Channels:Typically supports 16 digital inputs and 16 digital outputs
Output Characteristics:Outputs are protected against reverse polarity and 24V DC forced power supply.Some output channels can be assigned to internal high-speed counters,such as terminal 46(A62,00).When the counter is operating in Mode 1 or 2(counting up),this output is only used by the counter.To use it as a normal digital output,ensure that the high-speed counter is not configured in Mode 1 or 2.
Physical Characteristics:
Dimensions:Approximately 180mm×125.5mm×21.5mm(for reference only,may vary slightly depending on production batches).
Appearance:Typically a black circuit board with two 64-pin connectors,two sets of 16 yellow LED indicators,and one red LED indicator.
Features:
High Reliability:Featuring a rugged design and high-quality electronic components,it offers strong anti-interference capabilities and can operate stably in harsh industrial environments.
Easy Integration:Supports multiple industrial communication protocols,enabling easy integration into ABB robot control systems and other automation control systems,enabling signal exchange and collaborative operation between devices.
Applications:
Widely used in industries such as automotive manufacturing,electronics manufacturing,machining,and petrochemicals,it can be used for status monitoring and control of various devices in robotic systems,such as controlling the opening and closing of robot grippers and detecting the position of workpieces.
