描述
ABB RVC6-15A是一款功率因数控制器，适用于工业和商业场合的功率因数控制。以下是其产品详情：
技术参数
工作电压：100-240V AC。
频率范围：50/60Hz。
电流输入：1A或5A（有效值）。
输入阻抗：小于0.1欧姆。
损耗：最大8VA。
输出接点：最大持续电流1.5A，最大峰值电流5A，最高电压440Vac，端子A的承载容量为16A连续电流。
报警接点：常开式，最大电流5A，额定/最大分断电压为250Vac/440Vac。
功率因数设定范围：0.7感性到0.7容性。
投切顺序：用户自定义。
断电复位延迟时间：40s。
工作温度：-10℃至60℃。
存储温度：-30℃至85℃。
外形尺寸：144mm×144mm×43mm。
重量：约0.4千克。
功能特点
测量与显示功能：可测量并显示电压、电流、功率因数、电压总谐波畸变率（THDV）、电流总谐波畸变率（THDI）等关键参数。
高效投切策略：具有完全可编程的投切顺序，结合整体开关、直接开关和循环开关等多种切换模式，可在负载快速变化的情况下控制功率因数，减少开关次数，避免不必要的中间切换，延长电容器和接触器的使用寿命。
保护与报警功能：具备过压/欠压保护和谐波失真（THDV）保护功能。当所有输出开启后6分钟内未达到目标功率因数、RVC内部温度超过85°C、达到过压/欠压限制、电源超出范围、THDV超标时，报警触点将被打开。
易于调试和使用：采用用户友好的操作界面，具有完整的自动设置功能，如自动测量启动电流（C/k）、开关顺序类型、相移、特殊连接等，调试简便，便于手动设置参数。
应用领域
适用于建筑、矿山、化工、造纸和纸浆、水泥、塑料、印刷以及食品工业等工业和商业场合的功率因数控制。
The ABB RVC6-15A is a power factor controller suitable for power factor control in industrial and commercial applications.Here are its product details:
Technical Specifications
Operating Voltage:100-240V AC.
Frequency Range:50/60Hz.
Current Input:1A or 5A(RMS).
Input Impedance:Less than 0.1 ohms.
Losses:Maximum 8VA.
Output Contacts:Maximum continuous current 1.5A,maximum peak current 5A,maximum voltage 440Vac,terminal A capacity is 16A continuous current.
Alarm Contacts:Normally open,maximum current 5A,rated/maximum breaking voltage 250Vac/440Vac.
Power Factor Setting Range:0.7 inductive to 0.7 capacitive.
Switching Sequence:User-defined.
Power-off Reset Delay Time:40s.
Operating temperature:-10℃to 60℃.
Storage temperature:-30℃to 85℃.
Dimensions:144mm×144mm×43mm.
Weight:Approx.0.4 kg.
Features
Measurement and display functions:Measures and displays key parameters such as voltage,current,power factor,total harmonic distortion(THDV)of voltage,and total harmonic distortion(THDI)of current.
Efficient switching strategy:Features a fully programmable switching sequence,combining multiple switching modes such as overall switching,direct switching,and cyclic switching.It can control the power factor under rapidly changing loads,reduce the number of switching operations,avoid unnecessary intermediate switching,and extend the lifespan of capacitors and contactors.
Protection and alarm functions:Equipped with overvoltage/undervoltage protection and harmonic distortion(THDV)protection.The alarm contacts will open if the target power factor is not reached within 6 minutes of all outputs being turned on,the RVC internal temperature exceeds 85°C,overvoltage/undervoltage limits are reached,the power supply is out of range,or THDV exceeds the limit.
Easy to debug and use:Features a user-friendly interface with complete automatic setting functions,such as automatic measurement of starting current(C/k),switching sequence type,phase shift,and special connections.Debugging is simple and manual parameter setting is convenient.
Applications:Suitable for power factor control in industrial and commercial settings such as construction,mining,chemical,paper and pulp,cement,plastics,printing,and food industries.
