描述
ABB SAFT120是一款专为工业自动化控制系统设计的智能电源模块，常见于ABB Advant系列或相关工业控制架构中，核心功能是为控制系统核心单元（如控制器、I/O模块）提供稳定、可靠的直流供电，同时具备完善的保护与诊断能力。以下是其详细产品信息：
一、基本参数
类别规格详情
产品类型工业级直流电源模块（专为控制系统配套设计）
输入电压范围宽幅交流输入：115~230V AC（50/60Hz，允许±10%波动），适配全球工业电网
输出电压主输出：+5V DC（典型负载电流10A，最大12A）、+12V DC（典型负载电流8A，最大10A）
辅助输出：+3.3V DC（可选，用于控制器核心芯片供电）
输出精度主输出电压精度±2%（满载条件下），纹波噪声≤50mV（峰峰值）
总输出功率额定功率80~100W（根据具体子型号略有差异，典型值90W）
物理尺寸紧凑型设计：约220mm（长）×110mm（宽）×55mm（高）（适配标准DIN导轨或机柜插槽安装）
重量约0.8~1.0kg（不含安装附件）
工作环境工作温度：-25℃~+60℃（工业宽温范围，适应恶劣车间环境）
相对湿度：5%~95%（无凝露）
防护等级：IP20（模块本体，需配合控制柜整体防护）
认证标准符合IEC 61010-1（工业控制设备安全标准）、CE（欧盟电磁兼容与安全认证）、RoHS（环保合规）
二、核心功能与产品特点
高稳定性供电
采用宽幅输入+高效DC/DC转换电路，可抵御电网电压波动（如电压暂降、浪涌），输出电压纹波小，确保控制器、I/O模块等敏感单元不受电源干扰，避免数据丢失或控制指令误触发。
具备动态负载响应能力：当负载电流瞬间变化（如I/O模块批量切换）时，输出电压恢复时间≤100μs，保障系统实时性。
全方位保护机制
内置多重保护功能，覆盖电源全生命周期风险：
短路保护：输出端短路时，模块自动切断输出，故障排除后可自恢复（或手动复位，根据型号设定）；
过载保护：负载超过额定功率120%时，触发限流保护，避免模块过热损坏；
过压/欠压保护：输入电压超出115~230V AC范围，或输出电压异常（如+5V升至5.5V以上）时，模块停机保护下游设备；
过温保护：模块内部温度超过85℃时，自动降额输出，温度降至安全范围后恢复正常。
The ABB SAFT120 is an intelligent power supply module designed specifically for industrial automation control systems.It is commonly used in ABB Advant series systems and other similar industrial control architectures.Its core function is to provide stable and reliable DC power to the core components of the control system(such as controllers and I/O modules),while also offering comprehensive protection and diagnostic capabilities.Here are the detailed product specifications:
I.Basic Parameters
Category Specification Details
Product Type Industrial-grade DC power supply module(designed specifically for control systems)
Input Voltage Range Wide AC input range:115~230V AC(50/60Hz,±10%tolerance),compatible with global industrial power grids
Output Voltage Main output:+5V DC(typical load current 10A,max 12A),+12V DC(typical load current 8A,max 10A)
Auxiliary output:+3.3V DC(optional,for powering the controller’s core chip)
Output Accuracy Main output voltage accuracy±2%(under full load),ripple and noise≤50mV(peak-to-peak)
Total Output Power Rated power 80~100W(varies slightly by model,typical value 90W)
Physical Dimensions Compact design:approx.220mm(L)×110mm(W)×55mm(H)(compatible with standard DIN rail or cabinet slot mounting)
Weight Approx.0.8~1.0kg(excluding mounting accessories)
Operating Environment Operating temperature:-25℃~+60℃(wide industrial temperature range,suitable for harsh factory environments)
Relative humidity:5%~95%(non-condensing)
Protection level:IP20(module itself,requires additional enclosure protection)
Certification Standards Compliant with IEC 61010-1(industrial control equipment safety standard),CE(EU EMC and safety certification),RoHS(environmental compliance)
II.Key Features and Functions
High-stability power supply
Utilizing a wide input range and an efficient DC/DC converter,it can withstand power grid fluctuations(such as voltage dips and surges),ensuring low output voltage ripple and protecting sensitive components like controllers and I/O modules from power supply interference,preventing data loss or erroneous control commands.
Dynamic load response capability:When the load current changes instantaneously(e.g.,during batch switching of I/O modules),the output voltage recovery time is≤100μs,ensuring real-time system performance.Comprehensive Protection Mechanisms
Built-in multiple protection functions cover all potential risks throughout the power supply’s lifecycle:
Short-circuit protection:In case of a short circuit at the output,the module automatically shuts down the output,and can self-recover after the fault is cleared(or manually reset,depending on the model);
Overload protection:When the load exceeds 120%of the rated power,current limiting protection is triggered to prevent module overheating and damage;
Overvoltage/Undervoltage protection:If the input voltage exceeds the 115-230V AC range,or if the output voltage is abnormal(e.g.,+5V rises above 5.5V),the module shuts down to protect downstream devices;
Over-temperature protection:When the internal temperature of the module exceeds 85°C,the output power is automatically reduced,and normal operation resumes once the temperature drops to a safe range.
