描述
ABB SB822 3BSE018172R1是一款可充电电池单元，主要用于为ABB相关控制系统提供备用电源。以下是其详细产品详情：
产品类型：可充电电池单元。
安装方式：采用DIN导轨安装，便于在控制柜内集成和固定。
主要功能：在主电源故障时，作为外部电源为AC 800M控制器提供备用电源，确保系统的持续运行，防止数据丢失，也可用于为其他通信设备和I/O系统供电。
电池类型：锂离子电池。
额定输出电压：3.6V。
最大输出电流：0.05A。
工作温度范围：0℃至55℃。
防护等级：IP20，符合IEC 60529标准。
尺寸：宽度85.8毫米，深度58.5毫米，高度136毫米。
重量：约550克。
The ABB SB822 3BSE018172R1 is a rechargeable battery unit primarily designed to provide backup power for ABB control systems.The following are detailed product details:
Product Type:Rechargeable Battery Unit.
Mounting Method:DIN rail mountable for easy integration and securement within a control cabinet.
Main Function:In the event of a main power failure,it provides backup power to the AC 800M controller as an external power supply,ensuring continuous system operation and preventing data loss.It can also be used to power other communication devices and I/O systems.
Battery Type:Lithium-ion battery.
Rated Output Voltage:3.6V.
Maximum Output Current:0.05A.
Operating Temperature Range:0°C to 55°C.
Protection Rating:IP20,in accordance with IEC 60529.
Dimensions:Width 85.8 mm,Depth 58.5 mm,Height 136 mm.
Weight:Approximately 550 grams.
