描述
ABB SC610是ABB Ability™System 800xA控制系统中的一款I/O模块，主要用于采集和控制模拟量信号，适用于石油和天然气、水处理等多种工业自动化场景。以下是其详细信息：
通道参数：具备8个模拟输入通道和8个模拟输出通道。
输入输出信号：输入信号支持0-10V DC、4-20mA DC，输出信号为0-10V DC、4-20mA DC。
分辨率与精度：分辨率为16位，精度可达±0.05%。
电源规格：输入电压为100-240V AC，输出电压为24V DC，最大电流消耗500mA，额定功率24W。
工作温度：工作温度范围为-20℃至60℃。
通信接口：支持Modbus TCP/IP、Profibus DP、Ethernet/IP等通信协议。
尺寸重量：尺寸约为300mm×210mm×35mm，重量约为0.5kg。
The ABB SC610 is an I/O module in the ABB Ability™System 800xA control system.It is primarily used for acquiring and controlling analog signals and is suitable for a variety of industrial automation scenarios,including oil and gas and water treatment.The following are its detailed information:
Channel Parameters:8 analog input channels and 8 analog output channels.
Input and Output Signals:Input signals support 0-10V DC and 4-20mA DC,while output signals support 0-10V DC and 4-20mA DC.
Resolution and Accuracy:16-bit resolution with an accuracy of±0.05%.
Power Supply Specifications:Input voltage is 100-240V AC,output voltage is 24V DC,maximum current consumption is 500mA,and rated power is 24W.
Operating Temperature:Operating temperature range is-20°C to 60°C.
Communication Interfaces:Supports Modbus TCP/IP,Profibus DP,Ethernet/IP,and other communication protocols.Dimensions and weight:Dimensions are approximately 300mm×210mm×35mm,and weight is approximately 0.5kg.
