描述
ABB TB511-ETH是一款专为AC500系列控制器设计的以太网终端基座。以下是其产品详情：
基本信息
品牌：ABB
型号：TB511-ETH
产品ID：1SAP111100R0270
产地：瑞典
重量：约0.159kg
尺寸：净深28mm，净高135mm，净宽95.5mm
技术参数
工作电压：24V DC
防护等级：IP20
通信接口：以太网接口（RJ45）、2个串行接口（RS232/RS485，COM1口为弹簧接线端子，COM2口为SUB D9型接口）
工作温度范围：0℃至+60℃
存储温度范围：-40℃至+70℃
功能特点
适配性强：为AC500 V2系列控制器配套的终端基座，提供1个通信模块插槽，可扩展通信功能。
通信接口丰富：集成以太网接口和2个串行接口，能够满足多种通信需求，方便与其他设备进行连接和数据传输。
安装方便：通常采用导轨安装方式，便于在工业控制柜中进行安装和布局。
The ABB TB511-ETH is an Ethernet terminal base designed specifically for the AC500 series controllers.Here are the product details:
Basic Information
Brand:ABB
Model:TB511-ETH
Product ID:1SAP111100R0270
Origin:Sweden
Weight:Approx.0.159kg
Dimensions:Depth 28mm,Height 135mm,Width 95.5mm
Technical Parameters
Operating Voltage:24V DC
Protection Level:IP20
Communication Interface:Ethernet port(RJ45),2 serial ports(RS232/RS485,COM1 port uses spring-type terminals,COM2 port uses SUB D9 connector)
Operating Temperature Range:0°C to+60°C
Storage Temperature Range:-40°C to+70°C
Features
High Compatibility:Designed as a terminal base for AC500 V2 series controllers,providing one communication module slot for expanded communication capabilities.
Rich Communication Interfaces:Integrates an Ethernet port and two serial ports,meeting various communication needs and facilitating connection and data transfer with other devices.
Easy Installation:Typically DIN rail mounted,facilitating installation and layout in industrial control cabinets.
