描述
基本信息
型号：TB820V2
产品类型：调制解调器控制总线模块/通讯接口模块
兼容性：支持ABB S800 I/O系统，可与DCS及PLC无缝集成
工作电压：5-24V DC
尺寸：50×50mm
安装方式：支持DIN导轨安装
防护等级：IP20
功能特点
接口丰富：拥有一个电气接口和一个光纤接口，电气接口最多可将12个I/O模块连接到电气模块总线，光纤接口可将7个集群连接到光纤模块总线，支持塑料光纤、HCS光纤与玻璃光纤之间的转换。
监控功能：能够对I/O模块总线和电源进行监控，实时反馈总线及电源的工作状态。
隔离供电：为I/O模块提供隔离电源，增强了系统的电气安全性，降低不同模块间的电气干扰。
配置方便：TB820V2系列模块配有一个旋转开关，用户可以在光模块总线上选择其簇号（1至7），方便进行系统的配置和管理。
Basic Information
Model:TB820V2
Product Type:Modem Control Bus Module/Communication Interface Module
Compatibility:Supports ABB S800 I/O system,seamlessly integrates with DCS and PLC systems
Operating Voltage:5-24V DC
Dimensions:50×50mm
Mounting Method:Supports DIN rail mounting
Protection Level:IP20
Features
Rich Interfaces:Features one electrical interface and one fiber optic interface.The electrical interface can connect up to 12 I/O modules to the electrical bus,while the fiber optic interface can connect 7 clusters to the fiber optic bus,supporting conversion between plastic fiber,HCS fiber,and glass fiber.
Monitoring Function:Monitors the I/O module bus and power supply,providing real-time feedback on the status of the bus and power supply.
Isolated Power Supply:Provides isolated power supply for the I/O modules,enhancing system electrical safety and reducing electrical interference between different modules.
Easy Configuration:The TB820V2 series module features a rotary switch,allowing users to select their cluster number(1 to 7)on the fiber optic bus,facilitating system configuration and management.
