描述
ABB TC514V2（核心订货型号3BSE013281R1）是一款适配工业自动化场景的高性能DCS冗余控制模块，兼具信号精准处理、多协议兼容及恶劣环境适配能力，常作为工业系统中设备互联与数据交互的核心组件，以下是整合多方渠道的详细产品信息：
核心电气与性能参数
参数类别具体规格
核心处理与精度搭载高性能处理单元，配备16位ADC/DAC转换器，信号处理精度达±0.1%，能精准转换模拟与数字信号，可有效减少压力、流量等关键工业参数监控中的数据误差。
I/O通道配置拥有8路模拟输入通道（适配4-20mA电流信号、0-10V电压信号）、16路数字输入通道（干触点类型）；同时配置4路模拟输出通道（4-20mA、0-10V）和8路数字输出通道（继电器类型，承载电流2A），可对接多种传感器与执行器。
供电与功耗采用24V直流供电，供电范围兼容18-30V DC，适配工业通用供电系统，最大功耗仅8W，能耗较低，适合长期连续运行场景。
通信与隔离性能支持Modbus RTU、Profibus DP等主流工业协议，配备1个RS-485端口，部分版本还兼容ControlNet协议，数据传输速率可达100Mbps；输入与输出端具备2.5kV电隔离设计，能有效抵御工业现场的电磁干扰，保障数据传输稳定。
物理与环境适配信息
物理规格：主流规格为120mm×80mm×60mm，重量约350g；也有120mm×100mm×40mm、20.3cm×5.1cm×15.2cm等版本记录，重量对应0.2kg-0.8kg不等。整体结构紧凑，可灵活嵌入工业控制柜内安装，无需占用过多空间。
环境适应能力：防护等级达IP20，可防止灰尘侵入；工作温度适配范围较广，主流标注为-10℃-60℃，部分渠道显示可拓展至-20℃-70℃；能应对工业现场的温度波动与轻微振动，同时满足长途运输和长期仓储的环境要求。
The ABB TC514V2(core order model 3BSE013281R1)is a high-performance DCS redundant control module adapted for industrial automation scenarios.It features precise signal processing,multi-protocol compatibility,and adaptability to harsh environments.It is often used as a core component for device interconnection and data interaction in industrial systems.The following is detailed product information compiled from multiple sources:
Core Electrical and Performance Parameters
Parameter Category Specific Specifications
Core Processing and Accuracy
Equipped with a high-performance processing unit and a 16-bit ADC/DAC converter,it achieves signal processing accuracy of±0.1%,accurately converting analog and digital signals and effectively reducing data errors in monitoring key industrial parameters such as pressure and flow.
I/O Channel Configuration:Features 8 analog input channels(compatible with 4-20mA current signals and 0-10V voltage signals)and 16 digital input channels(dry contact type);it also includes 4 analog output channels(4-20mA,0-10V)and 8 digital output channels(relay type,2A current carrying capacity),compatible with various sensors and actuators.
Power Supply and Power Consumption:Employs 24V DC power supply,compatible with 18-30V DC,suitable for general industrial power supply systems.Maximum power consumption is only 8W,making it low-energy and suitable for long-term continuous operation.
Communication and Isolation Performance:Supports mainstream industrial protocols such as Modbus RTU and Profibus DP,equipped with one RS-485 port.Some versions are also compatible with ControlNet protocol,with data transmission rates up to 100Mbps.The input and output terminals feature 2.5kV electrical isolation design,effectively resisting electromagnetic interference in industrial environments and ensuring stable data transmission.
Physical and Environmental Adaptability Information
Physical Specifications:The mainstream size is 120mm×80mm×60mm,weighing approximately 350g;versions also exist at 120mm×100mm×40mm and 20.3cm×5.1cm×15.2cm,with corresponding weights ranging from 0.2kg to 0.8kg.The compact design allows for flexible installation within industrial control cabinets without occupying excessive space.
Environmental Adaptability:IP20 protection rating prevents dust intrusion;wide operating temperature range,generally-10℃to 60℃,with some sources indicating an extension to-20℃to 70℃;capable of withstanding temperature fluctuations and minor vibrations in industrial environments,while also meeting the environmental requirements for long-distance transportation and long-term storage.
