描述
ABB TC630（订货型号3BSE002253R1）是一款适配Advant Fieldbus 100总线的工业级光调制解调器，核心用于工业场景中同轴与光纤信号的转换传输，适配多种工业控制系统，以下是详细产品详情：
核心功能与适配特性
信号转换与总线适配：该产品专为Advant Fieldbus 100总线设计，核心能力是实现同轴电缆与光纤之间的双向信号转换，解决工业现场不同传输介质的适配问题。同时兼容Profinet等工业通信协议，能无缝融入ABB Advant系列控制系统，也可适配分布式控制系统，适配新旧工业控制项目的改造与新建需求。
稳定传输保障：搭配2×65.5/125μm或100/400μm规格的光纤使用，采用ST型连接器，这种搭配能减少工业现场电磁干扰对信号的影响，相比传统电缆传输，大幅提升数据传输的抗干扰性和稳定性。其紧凑设计不仅便于安装，还能降低在控制柜内的空间占用，后期维护时插拔和检修也较为便捷。
合规与适配性强：符合欧盟RoHS指令2011/65/EU标准，属于WEEE 5类小型设备，无任一外部尺寸超过50厘米，契合工业环保回收相关要求，同时多数供应商提供12个月质保，保障设备长期稳定运行。
关键技术参数
参数类别具体规格
电气参数采用24V直流供电，适配工业领域主流的直流供电场景；另有少数渠道标注额定输入电压为26VDC，推测为测试工况下的极限适配电压，常规场景以24V直流为准。
物理规格尺寸标注统一，为47mm（深度/长度）×11mm（高度）×65mm（宽度）；净重稳定在0.715kg左右，不同供应商标注的720g、760g等差异，大概率是包装配件重量差异导致，整体小巧轻便，易于集成安装在控制柜内。
环境参数工作温度范围为-20°C至60°C，相对湿度0%-95%且无冷凝，能应对工业现场高低温、潮湿等复杂环境；防护等级为IP30，可抵御工业环境中的粉尘侵袭，适合安装在控制柜内长期运行。.
The ABB TC630(order model 3BSE002253R1)is an industrial-grade optical modem compatible with the Advant Fieldbus 100 bus.Its core function is to convert and transmit coaxial and fiber optic signals in industrial environments,adapting to various industrial control systems.Detailed product information is as follows:
Core Functions and Adaptation Features
Signal Conversion and Bus Adaptation:Designed specifically for the Advant Fieldbus 100 bus,its core capability is bidirectional signal conversion between coaxial cables and optical fibers,solving the compatibility issues of different transmission media in industrial settings.It is also compatible with industrial communication protocols such as Profinet,seamlessly integrating into ABB Advant series control systems and adapting to distributed control systems,meeting the needs of both new and upgraded industrial control projects.
Stable Transmission Guarantee:Used with 2×65.5/125μm or 100/400μm optical fibers and ST-type connectors,this configuration reduces the impact of electromagnetic interference on signals in industrial environments,significantly improving the anti-interference and stability of data transmission compared to traditional cable transmission.Its compact design not only facilitates installation but also reduces space occupation within the control cabinet,making plugging,unplugging,and maintenance easier in the future.
Strong Compliance and Adaptability:Complies with EU RoHS Directive 2011/65/EU,belongs to WEEE Category 5 small equipment,with no external dimensions exceeding 50 cm,meeting industrial environmental recycling requirements.Most suppliers also offer a 12-month warranty,ensuring long-term stable operation.
Key Technical Parameters
Parameter Category
Specific Specifications
Electrical Parameters
Uses 24V DC power supply,adaptable to mainstream DC power supply scenarios in the industrial field;a few sources indicate a rated input voltage of 26VDC,presumably the extreme adaptation voltage under test conditions;24V DC is the standard for normal scenarios.
Physical Specifications:Dimensions are uniformly marked as 47mm(depth/length)×11mm(height)×65mm(width);net weight is consistently around 0.715kg.Differences in weight(720g,760g,etc.)listed by different suppliers are likely due to variations in packaging and accessories.The overall design is compact and lightweight,facilitating easy integration and installation within a control cabinet.
Environmental Parameters:Operating temperature range is-20°C to 60°C,relative humidity 0%-95%with no condensation,capable of handling complex industrial environments with high and low temperatures and high humidity;IP30 protection rating,resistant to dust in industrial environments,suitable for long-term operation within a control cabinet.
