描述
1.主要功能与特点
CAN总线终端功能：提供正确的阻抗水平，用于直接在CI 910F CAN总线接口模块上终止三条CAN总线线路
集成终端电阻：内置不可停用的终端电阻，确保信号完整性
连接器规格：配备9针D-SUB公头连接器，支持6个螺丝终端连接
物理保护：设计有电缆屏蔽和应变消除区域，有效防止电缆损坏和信号干扰1
2.典型应用场景
系统连接：用于连接Freelance I/O机架与CI 910F CAN总线接口模块
电缆兼容：可连接TK 811F开放式CAN电缆或商业双绞线电缆
配置支持：适用于单机或冗余控制器配置环境
位置要求：安装在控制器与Freelance I/O机架上CAN总线的连接位置1
1.Main Functions and Features
CAN Bus Termination Function:Provides the correct impedance level for direct termination of three CAN bus lines on the CI 910F CAN bus interface module.
Integrated Termination Resistor:Built-in non-disabled termination resistor ensures signal integrity.
Connector Specifications:Equipped with a 9-pin D-SUB male connector,supporting 6-screw termination connections.
Physical Protection:Designed with cable shielding and strain relief areas to effectively prevent cable damage and signal interference.
2.Typical Application Scenarios
System Connection:Used to connect the Freelance I/O rack to the CI 910F CAN bus interface module.
Cable Compatibility:Can connect to TK 811F open CAN cable or commercial twisted-pair cable.
Configuration Support:Suitable for standalone or redundant controller configuration environments.
Location Requirements:Connection location of the CAN bus on the controller and Freelance I/O rack.
