描述
ABB TU810V1是一款紧凑型模块终端单元（MTU），主要用于ABB S800 I/O系统中。以下是其产品详情：
基本信息
通道数：16
输入类型：数字量
额定绝缘电压：50V
输入电压：24V DC
负载电流：2A
响应时间：1ms
隔离电压：2500Vrms
尺寸：约64mm×170mm×58.5mm
重量：约0.2kg
防护等级：IP20
安装方式：DIN导轨安装
符合标准：IEC 61131-2、UL 508、CSA C22.2 No.142、GB/T 14048.1、GB/T 14048.5
功能特点
模块化设计：便于安装和维护，支持标准35mm DIN导轨安装。
多通道连接：支持多达16个现场信号通道和过程电源连接，满足复杂工业自动化系统的需求。
机械键控：通过两个机械键进行配置，防止插入错误的I/O模块，确保系统的稳定性和安全性。
通信能力：支持现场总线通信协议，如PROFIBUS等，实现与其他设备的无缝连接和数据交换。
状态指示：配备6个双色LED状态指示灯，方便用户实时监控模块的工作状态。
应用领域
广泛应用于数控机械、冶金、石油天然气、石油化工、化工、造纸印刷、纺织印染、机械、电子制造、塑料机械、电力、水利、水处理/环保、市政工程、锅炉供暖、能源、输配电等多个领域。
The ABB TU810V1 is a compact modular terminal unit(MTU)primarily used in the ABB S800 I/O system.Here are its product details:
Basic Information
Number of Channels:16
Input Type:Digital
Rated Insulation Voltage:50V
Input Voltage:24V DC
Load Current:2A
Response Time:1ms
Isolation Voltage:2500Vrms
Dimensions:Approx.64mm x 170mm x 58.5mm
Weight:Approx.0.2kg
Protection Class:IP20
Mounting Method:DIN rail mounting
Standards Compliance:IEC 61131-2,UL 508,CSA C22.2 No.142,GB/T 14048.1,GB/T 14048.5
Features
Modular Design:Facilitates easy installation and maintenance;supports standard 35mm DIN rail mounting.
Multi-Channel Connectivity:Supports up to 16 field signal channels and process power connections,meeting the needs of complex industrial automation systems.
Mechanical Keying:Configured with two mechanical keys to prevent incorrect I/O module insertion,ensuring system stability and safety.
Communication Capabilities:Supports fieldbus communication protocols such as PROFIBUS,enabling seamless connection and data exchange with other devices.
Status Indication:Equipped with 6 dual-color LED status indicators for real-time monitoring of the module’s operating status.
Applications
Widely used in various industries including CNC machinery,metallurgy,oil and gas,petrochemical,chemical processing,paper and printing,textile dyeing,machinery manufacturing,electronics,plastics processing,power generation,water treatment/environmental protection,municipal engineering,boiler systems,energy,and power transmission and distribution.
