描述
ABB TU810V1 3BSE013230R1是一款紧凑型模块终端单元（MTU），主要用于ABB S800 I/O系统。以下是其产品详情：
基本信息
型号：TU810V1
部件编号：3BSE013230R1
尺寸：64mm（深度）×170mm（高度）×58.5mm（宽度）
重量：0.2kg
工作电压：DC 9-36V，典型值为DC 24V
电压等级：50V
通道数：16通道（2×8信号端子）
安装方式：DIN导轨安装
功能特性
信号传输与分配：作为I/O模块和现场设备之间的连接桥梁，负责信号的可靠传输与分配，可将单个信号分配到多个连接点，或将多个信号连接到单个控制模块。
地址生成：通过将输出位置信号移位到下一个MTU，生成到I/O模块的正确地址。
配置方式：使用两个机械键为不同类型的I/O模块配置MTU，提供总共36种不同的配置选项，确保模块的正确安装和使用。
通信能力：支持现场总线通信协议，如PROFIBUS等，具备9针的Sub_D插孔连接器，管脚定义符合Profibus DP的协议规范，支持多种通信速率，如9.6kBit/s、19.2kBit/s、45.45kBit/s等。
电气保护：具备4000V的防雷击以及1.5A的过流保护和600W浪涌保护功能，提高模块的抗干扰能力和安全性。
状态指示：配备6个双色LED状态指示灯，用于显示模块的工作状态和故障信息。
应用领域
广泛应用于数控机械、冶金、石油天然气、化工、造纸印刷、电力、水利、水处理等多个领域，特别适用于需要扩展工业控制系统的输入/输出（I/O）容量、采集各种传感器的数据以进行过程监测和控制等场景。
The ABB TU810V1 3BSE013230R1 is a compact modular terminal unit(MTU)designed primarily for the ABB S800 I/O system.Product details are as follows:
Basic Information
Model:TU810V1
Part Number:3BSE013230R1
Dimensions:64mm(depth)×170mm(height)×58.5mm(width)
Weight:0.2kg
Operating Voltage:DC 9-36V,typical DC 24V
Voltage Level:50V
Number of Channels:16 channels(2×8 signal terminals)
Mounting Method:DIN rail mount
Functional Features
Signal Transmission and Distribution:Serves as a bridge between I/O modules and field devices,ensuring reliable signal transmission and distribution.It can distribute a single signal to multiple connection points or connect multiple signals to a single control module.
Address Generation:Generates the correct address for the I/O module by shifting the output position signal to the next MTU.
Configuration:Two mechanical keys configure the MTU for different I/O module types,providing a total of 36 different configuration options,ensuring correct module installation and use.
Communication Capabilities:Supports fieldbus communication protocols such as PROFIBUS,featuring a 9-pin Sub-D receptacle connector.The pinout conforms to the Profibus DP protocol and supports multiple communication rates,such as 9.6kBit/s,19.2kBit/s,and 45.45kBit/s.
Electrical Protection:4000V lightning protection,1.5A overcurrent protection,and 600W surge protection enhance the module’s anti-interference capabilities and safety.
Status Indicators:Equipped with six dual-color LED status indicators to display module operating status and fault information.Application Areas:Widely used in a variety of fields,including CNC machinery,metallurgy,oil and gas,chemicals,papermaking and printing,power generation,water conservancy,and water treatment.It is particularly well-suited for scenarios requiring the expansion of input/output(I/O)capacity in industrial control systems and the collection of data from various sensors for process monitoring and control.
