描述
ABB TU812V1 3BSE013232R1是用于ABB S800 I/O系统的紧凑型模块终端单元（MTU）。以下是其产品详情：
基本信息
品牌：ABB
型号：TU812V1
货号：3BSE013232R1
额定电压：50V
通道数：16
连接方式：25针D-sub连接器
安装方式：双向安装，水平安装时工作温度为55℃，垂直安装时工作温度为40℃
尺寸：长64mm，高170mm，宽58.5mm
重量：约0.2kg
功能特点
信号连接与分配：作为连接现场布线的无源单元，包含ModuleBus的一部分，可将ModuleBus分发到I/O模块和下一个MTU，还能通过将输出位置信号转移到下一个MTU来生成I/O模块的正确地址。
配置灵活性：通过两个机械键为不同类型的I/O模块配置MTU，每个键有六个位置，总共有36种不同的配置，这种机械配置不影响MTU或I/O模块的功能。
The ABB TU812V1 3BSE013232R1 is a compact module terminal unit(MTU)for the ABB S800 I/O system.Product details are as follows:
Basic Information
Brand:ABB
Model:TU812V1
Article Number:3BSE013232R1
Rated Voltage:50V
Number of Channels:16
Connection Method:25-pin D-sub connector
Mounting Method:Bidirectional,operating temperature 55°C when mounted horizontally,40°C when mounted vertically
Dimensions:64mm long,170mm high,58.5mm wide
Weight:Approximately 0.2kg
Features
Signal Connection and Distribution:A passive unit that connects to field wiring,it includes a portion of the ModuleBus and distributes the ModuleBus to the I/O modules and the next MTU.It also generates the correct address for the I/O modules by transferring the output position signal to the next MTU.Configuration flexibility:The MTU is configured for different I/O module types via two mechanical keys,each with six positions,for a total of 36 different configurations.This mechanical configuration does not affect the functionality of the MTU or I/O modules.
