描述
ABB TU814V1是一款用于ABB S800 I/O系统的紧凑型模块化终端单元（MTU）。以下是其产品详情：
基本信息
产品编号：3BSE013233R1
通道数：16
额定绝缘电压：50V
输入电压：24V DC
每个I/O通道的最大电流：2A
最大电流过程连接：5A
可接受的线径：绞合0.2-0.5mm²（24-20AWG）；0.5-1.0mm²（20-18AWG）；1.5-2.5mm²（16-14AWG）
介电测试电压：500V AC
安装方式：支持标准35mm DIN导轨安装
防护等级：IP30
功能特点
模块化设计：允许用户根据实际需求选择不同的I/O模块，灵活配置系统，可连接AI810、AO810、DI810、DO810等多种I/O模块。
键控设计：通过两个机械键进行配置，每个键有六个位置，共有36种不同的配置，可防止模块错误安装，提高系统的可靠性。
信号连接与分配：作为被动单元，具有三排压接式快插连接器，用于现场信号和过程电源的连接，可将ModuleBus分配给I/O模块和下一个MTU，还通过将输出位置信号移位到下一个MTU来为I/O模块生成正确的地址。
状态指示：配备输入状态指示灯，方便用户实时监控模块的工作状态。
应用领域
过程控制：用于监测和控制生产过程中的各种参数，如温度、压力、流量等。
机器自动化：用于控制机器人的运动、设备的启动和停止等。
工厂自动化：用于实现整个工厂的自动化控制。
能源：用于能源系统的信号采集和控制。
水处理：用于水处理系统的自动化控制。
制药：用于制药行业的自动化控制。
食品饮料：用于食品饮料行业的自动化控制。
The ABB TU814V1 is a compact modular terminal unit(MTU)for the ABB S800 I/O system.Here are its product details:
Basic Information
Product Number:3BSE013233R1
Number of Channels:16
Rated Insulation Voltage:50V
Input Voltage:24V DC
Maximum Current per I/O Channel:2A
Maximum Current for Process Connection:5A
Acceptable Wire Sizes:Stranded 0.2-0.5mm²(24-20 AWG);0.5-1.0mm²(20-18 AWG);1.5-2.5mm²(16-14 AWG)
Dielectric Test Voltage:500V AC
Mounting Method:Supports standard 35mm DIN rail mounting
Protection Class:IP30
Features
Modular Design:Allows users to select different I/O modules according to their needs,flexibly configuring the system.Compatible with various I/O modules such as AI810,AO810,DI810,and DO810.
Keyed Design:Configured with two mechanical keys,each with six positions,providing 36 different configurations to prevent incorrect module installation and improve system reliability.
Signal Connection and Distribution:As a passive unit,it features three rows of push-in connectors for field signal and process power connections.It distributes the ModuleBus to I/O modules and the next MTU,and generates the correct address for the I/O modules by shifting the output position signal to the next MTU.
Status Indication:Equipped with input status LEDs for easy monitoring of the module’s operating status.
Applications
Process Control:Used for monitoring and controlling various parameters in production processes,such as temperature,pressure,and flow rate.
Machine Automation:Used for controlling robot movements,starting and stopping equipment,etc.
Factory Automation:Used for implementing automation control for an entire factory.
Energy:Used for signal acquisition and control in energy systems.
Water Treatment:Used for automation control in water treatment systems.
Pharmaceutical:Used for automation control in the pharmaceutical industry.
Food and Beverage:Used for automation control in the food and beverage industry.
