描述
ABB TU831V1 3BSE013235R1是一款扩展型模块终端单元，作为ABB S800 I/O系统的关键组件，专为工业自动化控制系统设计，提供高可靠性信号处理与模块扩展能力，适用于电力、石化、钢铁等行业的复杂工业环境1。
1.产品概述与核心功能
基本定位：作为可编程控制处理器模块底座，TU831V1 3BSE013235R1是ABB S800 I/O系统的核心组件，用于实现工业自动化设备的模块化扩展与信号处理
主要功能：提供4-8个模块扩展能力，支持高精度模拟信号处理和先进控制算法，可准确读取和处理各种工业传感器和执行器的信号
信号处理：适用于模拟量和数字量信号，支持多种输入输出信号类型，可处理工业现场常见的电压、电流等信号
系统集成：可与ABB系列模块（如AI830A、DI830等）及第三方设备（如西门子S7系列、施耐德Modicon M340）协同工作，形成完整的自动化解决方案23
2.技术规格与物理参数
物理特性：
尺寸：适配标准导轨安装（35mm DIN导轨）
重量：0.31KG
防护等级：IP20（适用于控制柜内环境）
安装方式：DIN导轨安装，支持快速安装与维护
电气特性：
电源：24VDC（标准工业电压）
额定电流：16A
电压范围：24V（支持工业标准电压）
支持导线截面积：0.2–2.5 mm²
工作温度范围：-25°C至+70°C，适应各种工业环境
通信特性：
通信接口：支持背板总线（如Profibus、EtherCAT）
兼容性：可与多种工业通信协议兼容，实现与其他自动化设备的数据交换
The ABB TU831V1 3BSE013235R1 is an extended modular terminal unit(MTU).As a key component of the ABB S800 I/O system,it is specifically designed for industrial automation control systems,providing highly reliable signal processing and modular expansion capabilities.It is suitable for complex industrial environments in industries such as power,petrochemicals,and steel.<sup>1</sup>
1.Product Overview and Core Functions
Basic Positioning:As a base for programmable controller processor modules,the TU831V1 3BSE013235R1 is a core component of the ABB S800 I/O system,used to realize modular expansion and signal processing of industrial automation equipment.
Main Functions:Provides 4-8 module expansion capabilities,supports high-precision analog signal processing and advanced control algorithms,and can accurately read and process signals from various industrial sensors and actuators.
Signal Processing:Suitable for analog and digital signals,supports multiple input and output signal types,and can process common industrial field signals such as voltage and current.
System Integration:Can work in conjunction with ABB series modules(such as AI830A,DI830,etc.)and third-party equipment(such as Siemens S7 series,Schneider Modicon M340)to form a complete automation solution.<sup>23</sup>
2.Technical Specifications and Physical Parameters
Physical Characteristics:
Dimensions:Adapts to standard DIN rail mounting(35mm)DIN rail mounting
Weight:0.31KG
Protection Class:IP20(suitable for control cabinet environments)
Installation Method:DIN rail mounting,supports quick installation and maintenance
Electrical Characteristics:
Power Supply:24VDC(standard industrial voltage)
Rated Current:16A
Voltage Range:24V(supports industrial standard voltage)
Supported Wire Cross-sectional Area:0.2–2.5 mm²
Operating Temperature Range:-25°C to+70°C,adaptable to various industrial environments
Communication Characteristics:
Communication Interface:Supports backplane bus(such as Profibus,EtherCAT)
Compatibility:Compatible with various industrial communication protocols,enabling data exchange with other automation equipment.
