描述
基本信息
产品类型：终端单元
重量：约0.55kg
尺寸：长×宽×高约为4.7cm×12.4cm×18.6cm
技术参数
电源输入：24V直流（19.2-30V）
模块总线电流分布：最大为5V 1.5A、24V 1.5A
额定绝缘电压：50V
介电测试电压：500V交流
功率消耗：2.0W
工作温度：水平安装时为55°C，垂直安装时为40°C
存储温度：-25°C至+70°C
机械钥匙：有36种不同组合
功能特点
冗余配置支持：设计用于光学模块总线调制解调器TB840/TB840A的冗余配置，确保主设备出现故障时，备用设备可无缝接管，保证系统的连续性和可靠性。
多种连接支持：支持冗余的输入/输出（I/O）连接，包括1个电源供应连接器终端和2个TB807模块总线终端，可满足不同设备的连接需求。
应用领域
工业自动化：可用于连接PLC、DCS系统、驱动器、电机等，实现对生产过程的监测和控制。
电力系统：可用于连接电力监测设备、保护装置、智能电表等，实现对电力系统的自动化管理和监控。
智能建筑：可用于连接空调系统、照明系统、安防系统等，实现对建筑物的智能化管理和控制。
Basic Information
Product Type:Terminal Unit
Weight:Approx.0.55kg
Dimensions:Approx.4.7cm(L)x 12.4cm(W)x 18.6cm(H)
Technical Parameters
Power Input:24V DC(19.2-30V)
Module Bus Current Distribution:Max.1.5A at 5V,1.5A at 24V
Rated Insulation Voltage:50V
Dielectric Test Voltage:500V AC
Power Consumption:2.0W
Operating Temperature:55°C(horizontal installation),40°C(vertical installation)
Storage Temperature:-25°C to+70°C
Mechanical Keying:36 different combinations available
Features
Redundancy Support:Designed for redundant configuration with the TB840/TB840A optical module bus modem,ensuring seamless handover to the standby device in case of primary device failure,guaranteeing system continuity and reliability.
Multiple Connection Support:Supports redundant input/output(I/O)connections,including 1 power supply connector terminal and 2 TB807 module bus terminals,meeting the connection needs of various devices.
Applications
Industrial Automation:Can be used to connect PLCs,DCS systems,drives,motors,etc.,for monitoring and controlling production processes.
Power Systems:Can be used to connect power monitoring equipment,protection devices,smart meters,etc.,for automated management and monitoring of power systems.
Smart Buildings:Can be used to connect HVAC systems,lighting systems,security systems,etc.,for intelligent management and control of buildings.
