描述
ABB TZIDC-200是一款智能电气定位器，V18348-10161310110是其具体型号标识，以下是产品详情：
基本信息
类型：电子可配置的定位器
应用场景：安装于气动线性或旋转执行器上，适用于需要隔爆外壳的危险区域。
通信功能：支持HART通信协议，标准配置有本地通信接口（LKS连接器）。
技术参数
输入信号：4-20mA两线制技术，标称范围4-20mA，分程范围可在标称范围的10%-100%之间配置，过流保护25mA/30V，最大电压降在4mA时为9.7V DC，20mA时电阻为485欧姆。
数字输入：控制电压12-24V DC，最大电流4mA。
输出范围：0-6bar（0-90psi），在1.4bar（20psi）供气压力下空气流量为5.0kg/h（3.9Nm³/h，2.3scfm），在6bar（90psi）供气压力下空气流量为13kg/h（10Nm³/h，6.0scfm）；若选择滑阀选项，输出范围为0-7bar（0-100psi），7bar（100psi）时空气流量为45kg/h（20.0scfm）。
空气供应：仪表空气应无油、无水、无灰尘，符合DIN/ISO 8573-1标准，污染和油含量符合3级，露点比工作温度低10K，供应压力为1.4-6bar（20-90psi），滑阀选项时为1.4-7bar（20-100psi）。
工作温度范围：-40℃至+85℃。
分辨率：A/D转换分辨率大于4000步，采样率为20ms。
功能特点
控制参数自动调节：可全自动确定控制参数并自适应定位器，实现最佳控制状态。
故障安全与故障闭锁功能：“故障安全”功能下，电源故障时定位器输出1减压，气动执行器的复位弹簧将阀门移动到安全位置，双作用执行器的输出2还会增压；“故障闭锁”功能下，电源故障时定位器输出1和输出2（如有）关闭，气动执行器将阀门锁定在当前位置，压缩空气供应故障时，定位器使执行器减压。
操作与调试便捷：配备内置操作面板，包含一个2线LCD指示器和4个操作按钮，用于现场操作期间的调试、配置和监控，也可通过提供的通信接口使用适当的配置程序进行操作。
认证齐全：具有ATEX、FM、CSA和IECEx等认证，适用于SIL2安全回路。
The ABB TZIDC-200 is an intelligent electrical positioner.Model number V18348-10161310110 is its specific identifier.Product details are as follows:
Basic Information
Type:Electronically configurable positioner
Applications:Mounted on pneumatic linear or rotary actuators,suitable for hazardous areas requiring flameproof enclosures.
Communications:Supports HART communication protocol and comes standard with a local communication interface(LKS connector).
Technical Parameters
Input Signal:4-20mA two-wire technology,nominal range 4-20mA,split range configurable from 10%to 100%of nominal range,overcurrent protection 25mA/30V,maximum voltage drop 9.7V DC at 4mA,resistance 485 ohms at 20mA.
Digital Input:Control voltage 12-24V DC,maximum current 4mA.Output range:0-6 bar(0-90 psi),air flow rate is 5.0 kg/h(3.9 Nm³/h,2.3 scfm)at a supply pressure of 1.4 bar(20 psi),and air flow rate is 13 kg/h(10 Nm³/h,6.0 scfm)at a supply pressure of 6 bar(90 psi).With the spool valve option,the output range is 0-7 bar(0-100 psi),and air flow rate is 45 kg/h(20.0 scfm)at 7 bar(100 psi).
Air supply:Instrument air should be oil-,water-,and dust-free according to DIN/ISO 8573-1,with contamination and oil content class 3 and a dew point 10K below the operating temperature.Supply pressure is 1.4-6 bar(20-90 psi),or 1.4-7 bar(20-100 psi)with the spool valve option.
Operating temperature range:-40°C to+85°C.
Resolution:A/D conversion resolution greater than 4000 steps,sampling rate 20ms.
Features
Automatic control parameter adjustment:Control parameters are fully automatically determined and the positioner is adaptively adjusted to achieve optimal control.
Fail-safe and fail-lockout functions:In the”fail-safe”function,positioner Output 1 is depressurized in the event of a power failure,the pneumatic actuator’s return spring moves the valve to a safe position,and Output 2 of the double-acting actuator is pressurized.In the”fail-lockout”function,positioner Output 1 and Output 2(if available)are closed in the event of a power failure,and the pneumatic actuator locks the valve in its current position.In the event of a compressed air supply failure,the positioner depressurizes the actuator.
Easy operation and commissioning:A built-in operator panel with a 2-line LCD indicator and four operating buttons is provided for commissioning,configuration,and monitoring during on-site operation.Operation can also be performed via the provided communication interface using an appropriate configuration program.Comprehensive certifications:ATEX,FM,CSA,and IECEx certified,suitable for SIL2 safety circuits.
