描述
ABB UA C383 AE01是一款高性能的工业自动化模块，属于ABB的HIEE300890R0001系列。以下是其产品详情：
基本信息
产品编号：HIEE300890R0001
电源供应：12V DC
工作温度范围：-40°C至85°C
防护等级：IP20
尺寸：50mm x 50mm x 10mm
硬件规格
CPU：32位RISC工业级ARM9处理器，180MHz主频
内存：DRAM为32MB，Nor Flash为8MB，Nand Flash可选64MB/128MB/256MB
通信接口：包括1个RS232串口（DEBUG Console，DB9-Male）、1个RS485串口（DB9-Male）、1个10/100M自适应以太网口（RJ45型插槽，1.5kv电磁隔离保护）以及GSM/GPRS蜂窝通信单元（射频波段900/1800MHz，GPRS Class12，支持SMS和APN接入，支持软件控制开关，配备SIM卡槽）
输入输出接口：8路可控模拟量采集端口，其中6路量程为4-20mA电流信号，支持两线制传感器，2路量程为0-40V电压信号，分辨率为12位；2路开关量采集端口；3路可控电源输出端口。
功能特点
多种功能集成：具备信号采集、智能通讯、数据传输、网络接入等功能。
操作系统支持：安装运行开源Linux2.6操作系统，有大量丰富的软件模块可借鉴，便于客户快速组建和部署业务逻辑。
灵活配置：可设置数据位、停止位、校验位、流控、波特率等参数，支持多通道输入输出配置，满足不同应用场景的需求。
The ABB UA C383 AE01 is a high-performance industrial automation module that belongs to ABB’s HIEE300890R0001 series.The following are product details:
Basic Information
Product Number:HIEE300890R0001
Power Supply:12V DC
Operating Temperature Range:-40°C to 85°C
Ingress Protection:IP20
Dimensions:50mm x 50mm x 10mm
Hardware Specifications
CPU:32-bit RISC industrial-grade ARM9 processor,180MHz clock speed
Memory:32MB DRAM,8MB NAND Flash,64MB/128MB/256MB Nand Flash options
Communication Interfaces:Includes one RS232 serial port(DEBUG console,DB9-male),one RS485 serial port(DB9-male),one 10/100M adaptive Ethernet port(RJ45 socket,1.5kV electromagnetic isolation protection),and a GSM/GPRS cellular communication unit(RF band 900/1800MHz,GPRS Class 12,supports SMS and APN access,supports software-controlled on/off,and is equipped with a SIM card slot.
Input and output interfaces:8 controllable analog acquisition ports,6 of which have a 4-20mA current range and support two-wire sensors,and 2 have a 0-40V voltage range with 12-bit resolution;2 digital acquisition ports;and 3 controllable power output ports.
Features
Multiple integrated functions:Provides signal acquisition,intelligent communication,data transmission,and network access.
Operating system support:Installs and runs the open-source Linux 2.6 operating system,with a rich library of software modules available for quick deployment and building of business logic.
Flexible configuration:Parameters such as data bits,stop bits,parity,flow control,and baud rate can be set.Multi-channel input and output configurations are supported to meet the needs of diverse application scenarios.
