描述
ABB UFC760BE41是一款高性能的工业自动化控制模块，通常用于ABB AC 800M系列控制器或Symphony Plus系统中。以下是其产品详情：
基本信息
品牌：ABB
型号：UFC760BE41
产品编号：3BHE004573R0041
外形尺寸：132mm×105mm×52mm
净重：800g
原产国：瑞典
技术参数
电源：双电源冗余输入，DC（9-36）V，典型DC24V，功耗小于4W，具有DC1500V电压隔离以及反接保护功能。
通信接口：数据电接口为9针的Sub_D插孔连接器，支持Profibus DP总线标准，通信速率包括9.6kBit/s、19.2kBit/s、45.45kBit/s、93.75kBit/s、187.5kBit/s、500kBit/s、1.5MBit/s、6MBit/s和12MBit/s，速率可自动识别或通过拨码开关设置；光纤接口可选，光纤波长多模为850nm、1310nm，单模为1310nm、1550nm，传输光纤多模为50/125um、62.5/125um、100/140um，单模为8.3/125um、9/125um、10/125um，传输距离多模为2Km，单模为20Km，光纤接口类型SC、FC、ST可选，标配SC光接口。
工作环境：工作温度为-10℃至+70℃，可选宽温-40℃至+85℃，相对湿度≤90%（无冷凝），存放温度为-40℃至+80℃。
功能特点
多协议通信支持：支持Profibus DP、Modbus TCP/IP、OPC UA等主流工业协议，兼容第三方设备。
冗余设计：支持双电源输入和冗余通信通道，符合IEC 61508 SIL2/SIL3安全标准，提升系统可靠性。
高性能处理：内置专用处理器，适用于实时数据采集和高速控制任务，响应时间低至毫秒级。
模块化与维护方便：支持热插拔更换，维护时无需停机，降低生产中断风险，可通过LED指示灯显示运行状态。
应用领域
过程自动化：可在化工厂中连接AC 800M控制器与现场仪表，实现实时数据采集。
电力系统监控：用于变电站自动化或发电机组控制，集成保护装置与上位系统。
制造执行系统：通过OPC UA协议将生产线数据上传至MES或ERP系统，支持生产优化。
油气管道SCADA：构建冗余通信网络，确保远程站点与控制中心的数据可靠传输。
The ABB UFC760BE41 is a high-performance industrial automation control module,typically used in ABB AC 800M series controllers or Symphony Plus systems.Product details are as follows:
Basic Information
Brand:ABB
Model:UFC760BE41
Product Number:3BHE004573R0041
Dimensions:132mm×105mm×52mm
Net Weight:800g
Country of Origin:Sweden
Technical Parameters
Power Supply:Dual redundant power inputs,DC(9-36)V,typical DC 24V,power consumption less than 4W,DC 1500V isolation,and reverse polarity protection.Communication interface:The data electrical interface is a 9-pin Sub_D jack connector that supports the Profibus DP bus standard.The communication rates include 9.6kBit/s,19.2kBit/s,45.45kBit/s,93.75kBit/s,187.5kBit/s,500kBit/s,1.5MBit/s,6MBit/s and 12MBit/s.The rate can be automatically identified or set by the DIP switch.The optical fiber interface is optional.The optical fiber wavelength is 850nm and 1310nm for multimode and 1310nm and 1550nm for single mode.The transmission optical fiber multimode is 50/125um,62.5/125um,and 100/140um,and the single mode is 8.3/125um,9/125um,and 10/125um.The transmission distance is 2km for multimode and 20km for single mode.The optical fiber interface type SC,FC,and ST options are available,with an SC optical interface standard.
Operating Environment:Operating temperature:-10°C to+70°C,with an optional wide operating temperature range of-40°C to+85°C.Relative humidity≤90%(non-condensing).Storage temperature:-40°C to+80°C.
Features
Multi-protocol Communication Support:Supports mainstream industrial protocols such as Profibus DP,Modbus TCP/IP,and OPC UA,and is compatible with third-party devices.
Redundant Design:Supports dual power inputs and redundant communication channels,complies with IEC 61508 SIL2/SIL3 safety standards,and enhances system reliability.
High-Performance Processing:Built-in dedicated processors are suitable for real-time data acquisition and high-speed control tasks,with response times as low as milliseconds.
Modularity and Easy Maintenance:Hot-swappable replacement is supported,eliminating downtime for maintenance,reducing the risk of production interruptions.LED indicators display operating status.
Applications
Process Automation:Connects the AC 800M controller to field instruments in chemical plants for real-time data acquisition.Power System Monitoring:Used for substation automation or generator set control,integrating protection devices with higher-level systems.
Manufacturing Execution Systems:Upload production line data to MES or ERP systems via the OPC UA protocol to support production optimization.
Oil and Gas Pipeline SCADA:Build redundant communication networks to ensure reliable data transmission between remote sites and the control center.
