描述
ABB UNITROL 1010是一款用于间接励磁同步电机的自动电压调节器（AVR），属于ABB UNITROL 1000系列。以下是其产品详情：
基本信息
输入电压：200-240VAC
输出电压：0-200VAC
输出电流：1.0-1.5A
功率损耗：100W
尺寸：19″标准机架尺寸
重量：0.5kg
防护等级：IP67
工作温度：-20℃至70℃
功能特点
控制模式多样：具备自动电压控制功能，采用可调PID控制器；支持功率因数和无功功率控制，带有PID控制算法；还可进行励磁电流调节，采用PI控制。
运行模式丰富：支持孤岛运行时并联发电机的无功功率分配，具备自动同步和同步前电压匹配功能。
监测与保护功能强大：通过可靠的CAN总线为冗余通道系统提供备用功能和设定点跟踪功能；具有电压互感器监测、同步检查功能、旋转二极管监测功能（RDM）以及各种限制器功能，如励磁电流限制器等。
数据记录与通信便捷：支持自动和手动触发数据记录器，记录测量值和用户选择的数据；具备事件记录器功能，记录带有时间和日期信息的成功信息；可通过标准以太网和RS485进行全功能Modbus通信，也可通过强大的调节器LCD面板轻松配置和读取测量值，还可使用CMT 1000调试和维护软件工具进行参数设置、监测、趋势分析和优化。
性能可靠：采用先进的微处理器技术和IGBT半导体器件，电流输出高达10ADC，可在严苛条件和不同温度范围下高性能工作，且完全符合DNV和UL标准。
The ABB UNITROL 1010 is an automatic voltage regulator(AVR)for indirect-excited synchronous motors,part of the ABB UNITROL 1000 series.The following are product details:
Basic Information
Input Voltage:200-240VAC
Output Voltage:0-200VAC
Output Current:1.0-1.5A
Power Consumption:100W
Dimensions:19″standard rack size
Weight:0.5kg
Protection Rating:IP67
Operating Temperature:-20°C to 70°C
Features
Various Control Modes:Automatic voltage control using an adjustable PID controller;power factor and reactive power control with a PID control algorithm;and excitation current regulation using PI control.
Comprehensive Operation Modes:Supports reactive power sharing between parallel generators during island operation,and features automatic synchronization and pre-synchronization voltage matching.
Powerful Monitoring and Protection Functions:Powerful monitoring and protection functions are implemented through a reliable CAN bus.The bus provides backup and setpoint tracking for redundant channel systems;it features voltage transformer monitoring,sync check,rotating diode monitoring(RDM),and various limiter functions,such as an excitation current limiter.
Easy Data Logging and Communication:The data logger supports automatic and manual triggering,recording measured valuesand user-selected data.An event logger function records success messages with time and date information.Full-featured Modbus communication is available via standard Ethernet and RS485.Measurements can be easily configured and read via the controller’s powerful LCD panel.The CMT 1000 commissioning and maintenance software tool allows for parameter setting,monitoring,trend analysis,and optimization.
Reliable Performance:Utilizing advanced microprocessor technology and IGBT semiconductor devices,it delivers a current output of up to 10 ADC,ensuring high-performance operation under harsh conditions and across a wide temperature range,and fully complies with DNV and UL standards.
