描述
ABB XO08R1是一款用于扩展ABB PLC输入/输出（I/O）能力的扩展模块，其部件号为1SBP260101R1001。以下是其产品详情：
基本信息
品牌：ABB
产地：法国
产品类型：数字输入/输出扩展模块
重量：约200g
技术参数
输出通道：8路继电器输出。
输出电压/电流：24V DC时2A，120V AC 50-60Hz时2A，230V AC 50-60Hz时2A。公共端C1/C2在24V DC时为8A，120V AC 50-60Hz时为8A，230V AC 50-60Hz时为8A。
功能特点
通道配置灵活：8个数字输入/输出被安排在一组，可单独用作输入、输出或可重读数输出。当用作数字输入时，输入信号延迟可配置为7ms（默认）或1ms。
输出状态监测：当用作数字输出时，输出信号“1”由可重读数输入单独监测。如果输出状态错误，将为相关输出组生成一个整体错误消息，并通过红色LED指示灯OVL和PLC的错误标志显示。
通信协议：使用标准的Modbus RTU通信协议进行通讯。
应用领域：可用于各种工业控制应用，包括机器人、自动化生产线、自动化仓储和物流系统等。
The ABB XO08R1 is an expansion module used to expand the input/output(I/O)capabilities of ABB PLCs.Its part number is 1SBP260101R1001.The following are product details:
Basic Information
Brand:ABB
Origin:France
Product Type:Digital I/O Expansion Module
Weight:Approximately 200g
Technical Parameters
Output Channels:8 relay outputs.
Output Voltage/Current:2A at 24V DC,2A at 120V AC 50-60Hz,2A at 230V AC 50-60Hz.Common terminals C1/C2 are 8A at 24V DC,8A at 120V AC 50-60Hz,and 8A at 230V AC 50-60Hz.
Features
Flexible channel configuration:8 digital inputs/outputs are arranged in groups and can be used individually as inputs,outputs,or re-readable outputs.When used as digital inputs,the input signal delay is configurable to 7ms(default)or 1ms.
Output status monitoring:When used as digital outputs,an output”1″signal is individually monitored by the re-readable input.If an output status error occurs,an overall error message is generated for the relevant output group and displayed via the red OVL LED and the PLC’s error flag.
Communication protocol:Communicates using the standard Modbus RTU protocol.
Applications:Suitable for a variety of industrial control applications,including robotics,automated production lines,automated warehousing,and logistics systems.
