一、产品定位与核心价值
1.产品定位
类型：混合信号I/O模块（Mixed Signal I/O Module），集模拟量输入（AI）、模拟量输出（AO）、数字量输入（DI）、数字量输出（DO）功能于一体，减少机柜空间占用和布线复杂度。
型号解析：
YB161102-AK：
YB161102：ABB内部物料编码，对应特定I/O通道配置（如8AI+4AO+16DI+8DO）。
AK：硬件版本或功能标识（可能对应防爆认证、高精度版本或特殊通信接口）。
系列背景：
该模块属于ABB Advant 800xA系统的紧凑型I/O解决方案，强调高集成度、高可靠性、易维护性，适用于对空间和成本敏感的中小型控制系统（如泵站、小型生产线、分布式控制节点）。
2.核心价值
高集成度：
单模块集成36个I/O通道（8AI+4AO+16DI+8DO），相比传统分立模块，可减少50%以上机柜空间和30%布线工作量。
多信号支持：
支持热电偶（TC）、热电阻（RTD）、毫伏（mV）、电流（4-20mA）、电压（0-10V）等模拟量信号，以及干接点、湿接点数字量信号，适配90%以上工业现场设备。
高精度与稳定性：
模拟量输入精度±0.1%FS，温度漂移<50ppm/℃，确保长期测量准确性（如化工反应釜温度控制）。
快速响应：
数字量输出响应时间<1ms，模拟量输出更新周期<10ms，满足高速控制需求（如电机启停、阀门调节）。
二、核心功能与技术参数
1.I/O通道配置
通道类型数量信号范围/类型分辨率隔离方式
模拟量输入（AI）8-热电偶：J/K/T/E/N/S/R/B型
-热电阻：Pt100/Cu50
-电压：0-10V/-10V~+10V
-电流：0-20mA/4-20mA 16位（热电偶）
14位（其他）通道间隔离（250V AC）
模拟量输出（AO）4-电压：0-10V/-10V~+10V
-电流：0-20mA/4-20mA 12位通道间隔离（250V AC）
数字量输入（DI）16-干接点：无源触点
-湿接点：24V DC（支持PNP/NPN）1位组隔离（500V AC）
数字量输出（DO）8-继电器输出：250V AC/30V DC，2A
-晶体管输出：24V DC，0.5A 1位组隔离（500V AC）
2.通信接口
总线类型：
通过CI854/CI858通信模块连接至ABB AC800M控制器，支持ControlNet、EtherNet/IP、PROFIBUS DP等协议。
数据传输速率：
依赖通信模块性能，例如EtherNet/IP模式下可达100Mbps，满足实时数据更新需求。
3.环境适应性
工作温度：
-20℃~+60℃（存储温度-40℃~+85℃），适应极端工业环境（如户外柜、高寒地区）。
防护等级：
IP20（标准机柜安装），若需防尘防水，可搭配IP54防护箱（如潮湿车间、粉尘环境）。
抗干扰能力：
符合IEC 61000-4-6（射频场抗扰度10V/m）和IEC 61000-4-4（电快速瞬变脉冲群抗扰度4kV）标准，适应强电磁环境（如变电站、电弧炉车间）。
防爆认证：
若型号为YB161102-AK-EX，则通过ATEX/IECEx认证，适用于爆炸性气体环境（Zone 1/2）（如化工车间、油气田）。
1.Product Positioning and Core Value
1.Product Positioning
Type:Mixed Signal I/O Module,integrating analog input(AI),analog output(AO),digital input(DI),and digital output(DO)functions to reduce cabinet space occupation and wiring complexity.
Model analysis:
YB161102-AK:
YB161102:ABB internal material encoding,corresponding to specific I/O channel configurations(such as 8AI+4AO+16DI+8DO).
AK:Hardware version or function identification(may correspond to explosion-proof certification,high-precision version or special communication interface).
Series background:
This module is a compact I/O solution for the ABB Advant 800xA system,emphasizing high integration,high reliability,and easy maintenance.It is suitable for small and medium-sized control systems(such as pump stations,small production lines,distributed control nodes)that are space-and cost-sensitive.
2.Core Value
High integration:
The single module integrates 36 I/O channels(8AI+4AO+16DI+8DO),which can reduce cabinet space by more than 50%and wiring workload by 30%compared to traditional discrete modules.
Multi-signal support:
Supports analog signals such as thermocouple(TC),thermal resistance(RTD),millivolt(mV),current(4-20mA),voltage(0-10V),as well as digital signals for dry and wet contacts,and is suitable for more than 90%of industrial field equipment.
High precision and stability:
Analog input accuracy±0.1%FS,temperature drift<50ppm/℃,ensuring long-term measurement accuracy(such as chemical reactor temperature control).
Quick response:
Digital output response time<1ms,analog output update cycle<10ms,meet high-speed control needs(such as motor start and stop,valve adjustment).
2.Core functions and technical parameters
1.I/O channel configuration
Channel Type Number Signal Range/Type Resolution Isolation Method
Analog Input(AI)8-Thermocouple:J/K/T/E/N/S/R/B Type
-Thermal resistance:Pt100/Cu50
-Voltage:0-10V/-10V~+10V
-Current:0-20mA/4-20mA 16-bit(thermocouple)
14-bit(other)Channel Isolation(250V AC)
Analog output(AO)4-Voltage:0-10V/-10V~+10V
-Current:0-20mA/4-20mA 12-bit Channel Isolation(250V AC)
Digital Input(DI)16-Dry Contact:Passive Contact
-Wet contacts:24V DC(PNP/NPN support)1-bit Group isolation(500V AC)
Digital output(DO)8-Relay output:250V AC/30V DC,2A
-Transistor output:24V DC,0.5A 1-bit Group isolation(500V AC)
2.Communication interface
Bus Type:
Connect to the ABB AC800M controller through the CI854/CI858 communication module,supporting protocols such as ControlNet,EtherNet/IP,PROFIBUS DP.
Data transfer rate:
Relying on the performance of communication modules,such as 100Mbps in EtherNet/IP mode,meets the real-time data update requirements.
3.Environmental adaptability
Operating temperature:
-20℃~+60℃(storage temperature-40℃~+85℃),adapting to extreme industrial environments(such as outdoor cabinets,high-altitude areas).
Protection level:
IP20(standard cabinet installation),if dustproof and waterproof,it can be matched with IP54 protective boxes(such as humid workshops,dust environments).
Anti-interference ability:
Comply with IEC 61000-4-6(RF field immunity 10V/m)and IEC 61000-4-4(electrical fast transient pulse group immunity 4kV)standards,and adapt to strong electromagnetic environments(such as substations,arc furnace workshops).
Explosion-proof certification:
If the model is YB161102-AK-EX,it passes ATEX/IECEx certification and is suitable for explosive gas environments(Zone 1/2)(such as chemical workshops,oil and gas fields).
