ABB NMBP-01产品详情解析
ABB NMBP-01是ABB Ability™System 800xA自动化平台的核心扩展模块之一，定位为多协议工业通信网关与边缘控制器。它通过集成多种工业通信协议（如PROFIBUS、Modbus、EtherNet/IP等），实现现场设备（传感器、执行器、PLC等）与ABB控制系统之间的高效数据交互，同时支持本地逻辑处理与安全防护功能，广泛应用于工业自动化、能源管理、过程控制等领域。
一、产品核心定位
多协议兼容性
解决不同厂商设备间的协议不兼容问题（如西门子PROFIBUS与罗克韦尔EtherNet/IP的互通）。
支持主站/从站模式，可灵活接入现有系统（如作为PROFIBUS DP主站管理第三方从站设备）。
边缘计算能力
内置32位ARM Cortex-A8处理器（主频1GHz），支持本地数据预处理、逻辑运算（如PID控制、报警阈值判断）。
减少上位机（如800xA DCS）的数据处理负载，提升系统响应速度。
高可靠性设计
双网口冗余：支持EtherNet/IP链路冗余，网络中断时自动切换，确保通信连续性。
双电源输入：支持24V DC双电源冗余供电，避免单点故障导致模块停机。
工业级防护：工作温度范围-20℃~+70℃，抗振动（IEC 60068-2-6）、抗电磁干扰（EN 61000-6-2）。
二、关键技术参数
1.通信接口
接口类型规格
以太网-2×RJ45端口（10/100 Mbps，自适应）
-支持协议：EtherNet/IP、Modbus TCP/IP、OPC UA Server/Client
串口-1×RS-232/RS-485可选（通过跳线配置）
-波特率：300~115200 bps
-支持协议：Modbus RTU、PROFIBUS DP从站（需扩展卡）
现场总线扩展-可选插拔式扩展卡：
-PROFIBUS DP主站卡（支持124个从站）
-DeviceNet主站卡
-CANopen主站卡
ABB NMBP-01 Product Details
The ABB NMBP-01 is a core expansion module of the ABB Ability™System 800xA automation platform,positioned as a multi-protocol industrial communication gateway and edge controller.By integrating multiple industrial communication protocols(such as PROFIBUS,Modbus,and EtherNet/IP),it enables efficient data exchange between field devices(sensors,actuators,PLCs,etc.)and ABB control systems.It also supports local logic processing and safety protection functions,making it widely applicable in industrial automation,energy management,process control,and other fields.
1.Product Core Positioning
Multi-protocol Compatibility
Resolves protocol incompatibilities between devices from different manufacturers(for example,interoperability between Siemens PROFIBUS and Rockwell EtherNet/IP).
Supporting master/slave mode,it allows flexible integration into existing systems(for example,acting as a PROFIBUS DP master to manage third-party slave devices).Edge Computing Capabilities
A built-in 32-bit ARM Cortex-A8 processor(1GHz)supports local data pre-processing and logical operations(such as PID control and alarm threshold determination).
This reduces the data processing load on the host computer(such as the 800xA DCS)and improves system responsiveness.
High Reliability Design
Dual Network Port Redundancy:Supports EtherNet/IP link redundancy,automatically switching in the event of a network interruption to ensure communication continuity.
Dual Power Input:Supports dual 24V DC redundant power supplies to prevent single-point failures from causing module downtime.
Industrial-grade protection:Operating temperature range-20°C to+70°C,vibration resistance(IEC 60068-2-6),and electromagnetic interference resistance(EN 61000-6-2).II.Key Technical Parameters
1.Communication Interfaces
Interface Type Specifications
Ethernet-2 x RJ45 ports(10/100 Mbps,auto-sensing)
-Supported protocols:EtherNet/IP,Modbus TCP/IP,OPC UA Server/Client
Serial Port-1 x RS-232/RS-485(selectable)(configurable via jumper)
-Baud rate:300-115200 bps
-Supported protocols:Modbus RTU,PROFIBUS DP slave(expansion card required)
Fieldbus Expansion-Optional plug-in expansion cards:
-PROFIBUS DP master card(supports 124 slaves)
-DeviceNet master card
-CANopen master card
