描述
ABB NPCT-01C是一款脉冲计数/定时器模块，主要用于工业自动化控制系统。以下是其产品详情：
基本信息
品牌：ABB
重量：约0.92公斤
尺寸：45mm×75mm×105mm
防护等级：IP20
安装方式：标准导轨安装
技术规格
输入：2个数字输入，电压范围为±24至250VDC、110至230VAC±10%，24VDC时输入电流为10mA，115/230VAC时最大为4mA。
输出：2个继电器输出，最大电压为120VDC、250VAC，24VDC电阻负载时开关容量为8A，120VDC电阻负载时为0.4A，250VAC时为2000VA，最大连续电流为2Arms。
通信接口：RS485接口。
电源：工作电压一般为24VDC，电流消耗为50mA。
硬件设置：6个拨码开关用于设置节点号，1个拨码开关用于启用/禁用数字输入DI1的硬件滤波。
产品特点
多功能性：既可以作为脉冲计数器，也可以作为定时器使用。
可编程性：输入、输出、计数方式、时间基准等参数均可编程设置。
高精度：具有较高的计数精度和时间测量精度。
可靠性高：采用工业级设计，所有材料均通过UL/CSA认证，具有4kV 5/50ns的快速瞬态脉冲抗扰度（IEC 801-4），电磁发射符合EN 55022 B标准。
应用领域
广泛应用于工业自动化控制系统，如流水线、包装机、机床等，也可用于石油化工、电力、冶金等过程工业领域，还可用于测量运动部件的速度、位移等，以及采集生产过程中的各种数据进行分析和处理。
The ABB NPCT-01C is a pulse counter/timer module primarily used in industrial automation control systems.The following are product details:
Basic Information
Brand:ABB
Weight:Approximately 0.92 kg
Dimensions:45 mm×75 mm×105 mm
Protection Rating:IP20
Mounting Method:Standard DIN-rail mounting
Technical Specifications
Inputs:Two digital inputs,voltage range±24 to 250 VDC,110 to 230 VAC±10%,input current 10 mA at 24 VDC,maximum 4 mA at 115/230 VAC.
Outputs:Two relay outputs,maximum voltage 120 VDC,250 VAC,switching capacity 8 A at 24 VDC resistive load,0.4 A at 120 VDC resistive load,2000 VA at 250 VAC,maximum continuous current 2 Arms.
Communication Interface:RS485 interface.Power Supply:Operating voltage is typically 24VDC,current consumption is 50mA.
Hardware Settings:Six DIP switches are used to set the node number,and one DIP switch is used to enable/disable hardware filtering for digital input DI1.
Product Features
Versatility:Can be used as both a pulse counter and a timer.
Programmability:Inputs,outputs,counting mode,time base,and other parameters are programmable.
High Precision:Provides high counting and time measurement accuracy.
High Reliability:Utilizing an industrial-grade design,all materials are UL/CSA certified,with 4kV 5/50ns fast transient immunity(IEC 801-4)and electromagnetic emissions compliant with EN 55022 B.
Applications
Widely used in industrial automation control systems such as assembly lines,packaging machines,and machine tools.It can also be used in process industries such as petrochemicals,power generation,and metallurgy.It can also be used to measure the speed and displacement of moving parts,as well as collect and analyze various data from production processes.
