一、产品概述
ACQUISITIONLOGIC AL81G是一款高性能工业自动化模块，涵盖模数转换器板、数字量输出子模件、模拟输入电子模块等多种功能，广泛应用于数据采集、信号处理及工业控制系统。其设计注重高精度、高可靠性，支持多通道信号输入/输出，并兼容多种通信协议与工业总线接口。
二、核心功能与特点
模数转换能力
高分辨率转换：支持8位至16位精度，适用于模拟信号数字化处理。
快速采样率：最高支持1 GS/s采样率，带宽达DC-350 MHz，满足高频信号采集需求。
多通道支持：提供单通道或8通道配置，支持电压（0-10V、4-20mA）和电流信号输入，兼容热电偶等传感器。
数字量控制功能
输出通道：8个数字量输出通道，支持执行器、继电器等设备的精准控制。
触发与控制：支持预触发、后触发、延迟采样等功能，适用于复杂控制场景。
工业级可靠性
宽温工作：工作温度范围-25°C至+70°C，存储温度达-40°C至+85°C。
防护等级：IP67防护，适应户外或潮湿环境。
抗干扰设计：采用隔离电路和抗噪声技术，确保信号稳定性。
通信与集成
接口兼容性：支持PCI/PCI-E总线、以太网（Ethernet）、RS485等接口，便于与PLC、工业计算机或机器人系统集成。
协议支持：兼容Modbus、PROFINET等工业协议，支持远程监控与数据传输。
1.Product Overview
ACQUISITIONLOGIC AL81G is a high-performance industrial automation module covering various functions such as analog-to-digital converter board,digital output submodule,analog input electronic module,etc.,and is widely used in data acquisition,signal processing and industrial control systems.Its design focuses on high precision and high reliability,supports multi-channel signal input/output,and is compatible with multiple communication protocols and industrial bus interfaces.
2.Core functions and features
Analog-to-digital conversion capability
High resolution conversion:supports 8-bit to 16-bit accuracy,suitable for analog signal digitization processing.
Fast sampling rate:supports up to 1 GS/s sampling rate,with bandwidth up to DC-350 MHz,meeting the needs of high-frequency signal acquisition.
Multi-channel support:It provides single-channel or 8-channel configuration,supports voltage(0-10V,4-20mA)and current signal input,and is compatible with sensors such as thermocouples.
Digital control function
Output channel:8 digital output channels,supporting precise control of actuators,relays and other equipment.
Triggering and control:Supports functions such as pre-triggering,post-triggering,delayed sampling,etc.,and is suitable for complex control scenarios.
Industrial-grade reliability
Wide temperature operation:Operating temperature range-25°C to+70°C,storage temperature up to-40°C to+85°C.
Protection level:IP67 protection,adapted to outdoor or humid environments.
Anti-interference design:Use isolation circuits and anti-noise technology to ensure signal stability.
Communication and integration
Interface compatibility:Supports PCI/PCI-E bus,Ethernet(Ethernet),RS485 and other interfaces,which are convenient for integration with PLC,industrial computer or robotic systems.
Protocol support:compatible with industrial protocols such as Modbus,PROFINET,etc.,and supports remote monitoring and data transmission.
