描述
ACU-01B 3HNA024871-001是ABB公司推出的一款应用于工业自动化领域的产品，主要用于喷涂机器人的空气控制。以下是其产品详情：
基本信息
品牌：ABB
型号：ACU-01B 3HNA024871-001
产品类型：空气控制单元
重量：3.66kg
尺寸：210mm×140mm×160mm
工作电压：24V DC
功率：100W
技术参数
通信接口：有两个用于连接控制网络的RJ45以太网端口（CN1、CN2）和一个RJ45串行端口（COM4），COM4端口是隔离的，用于配置工具。
最大流量：100L/min
压力范围：0.5bar至10bar
模拟输入通道：8路，支持0-10V电压信号、4-20mA电流信号等多种标准模拟信号输入，输入阻抗≥1MΩ，测量精度可达±0.1%FS。
主要特点
高精度控制：采用高精度控制技术，可精确控制喷雾量和喷雾模式，将喷涂压力稳定控制在设定值的±0.1bar以内，空气流量波动控制在±2L/min范围内。
快速响应：能在100ms内迅速对参数变化做出响应，确保涂料均匀雾化，提升喷涂质量。
可靠性高：采用高可靠性的硬件和软件设计，工作温度范围为-40°C至80°C，湿度范围为5%至95%RH，能在恶劣的工业环境中稳定运行。
易于维护：内部采用工业级的密封技术，可有效防止外界灰尘、水分等物质的侵入，同时支持远程诊断和维护。
多通信协议兼容：支持Modbus RTU、Profibus DP、DeviceNet和以太网IP等多种通信协议，可实现与其他设备的无缝集成。
应用领域：广泛应用于表面处理、涂装、印刷、电子元件制造、食品加工等各种喷雾应用领域。
The ACU-01B 3HNA024871-001 is a product from ABB used in industrial automation,primarily for air control in painting robots.Below are its product details:
Basic Information
Brand:ABB
Model:ACU-01B 3HNA024871-001
Product Type:Air Control Unit
Weight:3.66kg
Dimensions:210mm×140mm×160mm
Operating Voltage:24V DC
Power:100W
Technical Specifications
Communication Interface:Two RJ45 Ethernet ports(CN1,CN2)for connecting to the control network and one RJ45 serial port(COM4).The COM4 port is isolated and used for configuration tools.
Maximum flow rate:100L/min
Pressure range:0.5bar to 10bar
Analog input channels:8 channels,supporting various standard analog signal inputs such as 0-10V voltage signals and 4-20mA current signals;input impedance≥1MΩ;measurement accuracy up to±0.1%FS.
Key Features
High-precision control:Employs high-precision control technology to precisely control spray volume and spray mode,stabilizing spray pressure within±0.1bar of the set value and controlling airflow fluctuations within±2L/min.
Fast response:Responds rapidly to parameter changes within 100ms,ensuring uniform coating atomization and improving spray quality.
High reliability:Utilizes highly reliable hardware and software design;operating temperature range-40°C to 80°C;humidity range 5%to 95%RH;stable operation in harsh industrial environments.
Easy to maintain:Utilizing industrial-grade sealing technology,it effectively prevents the intrusion of external dust,moisture,and other substances,while supporting remote diagnostics and maintenance.
Multi-communication protocol compatibility:Supports multiple communication protocols including Modbus RTU,Profibus DP,DeviceNet,and Ethernet IP,enabling seamless integration with other devices.
Application areas:Widely used in various spraying applications such as surface treatment,coating,printing,electronic component manufacturing,and food processing.
