ADTRON IC6RTB-01C-SA01 PLC控制系统技术说明
核心功能
模块化架构设计
由输入部分、CPU、采样部分、输出控制及通讯部分组成，支持灵活扩展与定制化配置。
输入部分：集成控制面板与输入模板，兼容传感器、执行器等外围设备连接。
采样部分：包含采样控制模板、AD转换模板及传感器，实现模拟量与数字信号的高精度采集。
输出控制：支持DA模板（模拟量输出）或直接输出模板（数字量驱动），适配执行器与功放设备。
通讯部分：通过通讯模板与上位机互联，支持工业网络协议（如Modbus、Profinet等）。
实时数据处理与控制
CPU核心：作为系统中枢，负责数据采集、逻辑运算及指令输出，支持多任务并行处理。
动态响应：采样周期可低至毫秒级，确保工业场景下的实时控制需求。
技术参数
硬件配置：
输入模板：支持数字量输入（DI）与模拟量输入（AI）混合配置。
输出模板：兼容数字量输出（DO）与模拟量输出（AO）模块化扩展。
通讯接口：支持RS485、以太网（10/100Base-T）等工业协议。
环境适应性：
工作温度：-20°C至60°C（工业级标准）。
抗干扰能力：EMC等级符合IEC 61000标准，适用于高电磁干扰环境。
安全等级：
支持SIL 2级安全认证（需结合具体配置）。
安全与可靠性
故障诊断与防护
微观诊断流程：
输入异常：检测操作失误或传感器故障。
输出异常：排查执行器损坏或驱动信号中断。
软件故障：通过实时监控程序识别逻辑错误或代码漏洞。
指示灯状态监测：CPU及电源模板提供故障指示灯，快速定位硬件异常。
冗余与容错设计
支持I/O模板热插拔，减少停机时间。
多层级数据校验机制，防止通信中断或数据丢失。
应用场景
工业自动化：生产线控制、机器人运动协调、仓储物流管理。
过程控制：化工、能源行业的温度、压力、流量实时监测与调节。
安全系统：紧急停机、毒气泄漏预警、设备过载保护。
ADTRON IC6RTB-01C-SA01 PLC control system technical description
Core functions
Modular architecture design
It consists of the input part,CPU,sampling part,output control and communication part,and supports flexible expansion and customized configuration.
Input part:Integrated control panel and input template,compatible with peripheral devices such as sensors and actuators.
Sampling part:It includes sampling control template,AD conversion template and sensor to achieve high-precision acquisition of analog quantity and digital signals.
Output control:supports DA template(analog output)or direct output template(digital drive),adapted to actuators and amplifier devices.
Communication part:It is interconnected with the upper computer through communication templates,and supports industrial network protocols(such as Modbus,Profinet,etc.).
Real-time data processing and control
CPU core:As the system center,it is responsible for data acquisition,logical operations and instruction output,and supports multi-task parallel processing.
Dynamic response:The sampling period can be as low as milliseconds to ensure real-time control requirements in industrial scenarios.
Technical parameters
Hardware configuration:
Input template:Supports a hybrid configuration of digital input(DI)and analog input(AI).
Output template:compatible with digital output(DO)and analog output(AO)modular expansion.
Communication interface:Supports industrial protocols such as RS485,Ethernet(10/100Base-T).
Environmental adaptability:
Operating temperature:-20°C to 60°C(industrial standard).
Anti-interference ability:EMC level complies with IEC 61000 standard and is suitable for high electromagnetic interference environments.
Safety Level:
Supports SIL Level 2 security certification(need to be combined with specific configuration).
Safety and reliability
Troubleshooting and protection
Microdiagnosis process:
Input abnormality:Detect operation error or sensor failure.
Output abnormality:troubleshooting the actuator damage or the driver signal is interrupted.
Software failure:Identification of logical errors or code vulnerabilities through real-time monitoring programs.
Indicator status monitoring:The CPU and power supply template provide fault indicators to quickly locate hardware abnormalities.
Redundancy and fault tolerance design
Supports hot-swap I/O templates to reduce downtime.
Multi-level data verification mechanism to prevent communication interruption or data loss.
Application scenarios
Industrial automation:production line control,robot motion coordination,warehousing and logistics management.
Process control:Real-time monitoring and regulation of temperature,pressure and flow in the chemical and energy industries.
Safety system:emergency shutdown,early warning of toxic gas leakage,equipment overload protection.
