描述
产品简要说明
AEG Modicon A020 s是施耐德电气（Electric）Modicon系列的数字量输入输出模块，专为工业自动化系统设计，核心特性包括：
多通道扩展：支持16通道数字量输入/输出，兼容24V DC电源
协议兼容性：适配Modbus RTU、EtherNet/IP等工业通信协议
环境适应性：IP20防护等级，适应工业环境温度与电磁干扰
产品详细说明
1.硬件架构与核心功能
模块化设计
物理接口：
输入通道：16路独立隔离数字量输入（支持NPN/PNP兼容）
输出通道：16路继电器输出（触点容量2A/250V AC）
通信特性：
主控兼容性：适配Modicon M340、Quantum系列控制器
通信接口：内置RS-485端口，支持Modbus RTU协议
电气特性
工作电压：24V DC±10%（输入/输出共用电源）
隔离保护：输入通道与输出通道之间电气隔离（耐压3000V AC）
2.环境适应性与可靠性
温度范围：-20℃至60℃（短期工作可扩展至70℃）
抗干扰能力：符合EN 61000-6-2/4标准（抗电磁干扰、浪涌保护）
冗余设计：支持双模块热备配置，故障切换时间<200ms
产品概述:AEG Modicon A020 s
作为Modicon系列的基础I/O扩展模块，其核心价值在于高密度通道集成与工业级可靠性：
技术亮点：
通道密度：单模块实现16路输入+16路输出，减少系统布线复杂度
快速响应：输入信号响应时间<5ms，输出指令执行延迟<10ms
行业适配：
智能制造：数控机床状态监控与执行机构控制
能源管理：光伏逆变器开关量信号采集与保护动作触发
物流分拣：输送带传感器信号处理与分拣机械臂动作控制
技术规格:AEG Modicon A020 s
参数项规格描述
通道数量输入16路，输出16路
输入类型NPN/PNP兼容（可配置）
输出类型继电器（触点容量2A/250V AC）
通信协议Modbus RTU、EtherNet/IP（需主控支持）
防护等级IP20（室内安装）
Product brief description
AEG Modicon A020s is a digital input and output module of Schneider Electric Modicon series,designed for industrial automation systems,with core features including:
Multi-channel expansion:Supports 16-channel digital input/output,compatible with 24V DC power supply
Protocol compatibility:adapted to industrial communication protocols such as Modbus RTU,EtherNet/IP
Environmental adaptability:IP20 protection level,adapt to industrial ambient temperature and electromagnetic interference
Product details
1.Hardware architecture and core functions
Modular design
Physical interface:
Input channel:16 independent isolated digital inputs(supports NPN/PNP compatibility)
Output channel:16 relay output(contact capacity 2A/250V AC)
Communication characteristics:
Master control compatibility:adapted to Modicon M340 and Quantum series controllers
Communication interface:built-in RS-485 port,supports Modbus RTU protocol
Electrical characteristics
Operating voltage:24V DC±10%(common power supply for input/output)
Isolation protection:electrical isolation between the input channel and the output channel(withstand voltage of 3000V AC)
2.Environmental adaptability and reliability
Temperature range:-20℃to 60℃(short-term work can be expanded to 70℃)
Anti-interference ability:complies with EN 61000-6-2/4 standard(anti-electromagnetic interference,surge protection)
Redundant design:supports dual module hot standby configuration,failover time<200ms
Product Overview:AEG Modicon A020s
As the basic I/O expansion module of the Modicon series,its core value lies in high-density channel integration and industrial-grade reliability:
Technical Highlights:
Channel density:Single module realizes 16 inputs+16 outputs,reducing system wiring complexity
Quick response:Input signal response time<5ms,output command execution delay<10ms
Industry adaptation:
Intelligent manufacturing:CNC machine tool status monitoring and actuator control
Energy management:Photovoltaic inverter switching signal acquisition and protection action trigger
Logistics sorting:Conveyor sensor signal processing and sorting robotic arm action control
Technical Specifications:AEG Modicon A020s
Parameters Specification Description
Number of channels:16 input channels,16 output channels
Input type NPN/PNP compatible(configurable)
Output type Relay(contact capacity 2A/250V AC)
Communication protocol Modbus RTU,EtherNet/IP(requires master control support)
Protection level IP20(Indoor installation)
