描述
产品简要说明
AEG Modicon AS-BDAP-218是施耐德电气（Schneider Electric）推出的工业级数字量输入模块，专为复杂自动化系统设计，具备以下核心特性：
高性能网络传输：支持Turbo Ring、Turbo Chain及RSTP/STP冗余协议，确保网络稳定性
隔离设计：16通道独立隔离输入，耐压2500V AC，适应恶劣工业环境
协议兼容性：支持Modbus/TCP、IPv6及IEEE 1588 PTP时钟同步，适配多种控制系统
产品详细说明
1.硬件架构与核心功能
输入通道设计
通道数量：16路独立隔离输入
输入类型：24-240V AC/DC兼容，最大电流0.5A
隔离耐压：通道间及电源隔离耐压2500V AC
网络通信与冗余
冗余协议：
Turbo Ring（环形拓扑）：故障自愈时间<50ms
Turbo Chain（链式拓扑）：支持快速链路切换
RSTP/STP（生成树协议）：防止网络环路
协议支持：
Modbus/TCP（设备管理与监控）
IPv6（符合IPv6 Ready认证）
IEEE 1588 PTP（精确时钟同步，精度<1μs）
电源与功耗
输入电压：24V DC（±10%）
功耗：≤5W（满载状态）
2.软件与系统集成
管理工具：支持SNMPv1/v2c/v3、RMON及Unity Pro软件
安全机制：
IEEE 802.1X端口认证
HTTPS/SSH加密通信
端口锁定（限制MAC地址访问）
诊断功能：
实时监测通道状态（短路、断线、过压）
自动报警（邮件通知与继电器输出）
Product brief description
AEG Modicon AS-BDAP-218 is an industrial-grade digital input module launched by Schneider Electric.It is designed for complex automation systems and has the following core features:
High-performance network transmission:supports Turbo Ring,Turbo Chain and RSTP/STP redundant protocols to ensure network stability
Isolation design:16 channels independent isolation input,with a voltage resistance of 2500V AC,adapting to harsh industrial environments
Protocol compatibility:Supports Modbus/TCP,IPv6 and IEEE 1588 PTP clock synchronization,adapted to multiple control systems
Product details
1.Hardware architecture and core functions
Input channel design
Number of channels:16 independent isolated inputs
Input type:24-240V AC/DC compatible,maximum current 0.5A
Isolation withstand voltage:2500V AC between channels and power supply
Network communication and redundancy
Redundant protocol:
Turbo Ring(Ring Topology):Failure self-healing time<50ms
Turbo Chain(chain topology):supports fast link switching
RSTP/STP(spanning tree protocol):prevents network loops
Protocol support:
Modbus/TCP(device management and monitoring)
IPv6(compliant with IPv6 Ready certification)
IEEE 1588 PTP(precise clock synchronization,accuracy<1μs)
Power and power consumption
Input voltage:24V DC(±10%)
Power consumption:≤5W(full load state)
2.Software and system integration
Management tools:Support SNMPv1/v2c/v3,RMON and Unity Pro software
Safety mechanism:
IEEE 802.1X port authentication
HTTPS/SSH Encrypted Communication
Port locking(restrict MAC address access)
Diagnostic function:
Real-time monitoring of channel status(short circuit,disconnection,overvoltage)
Automatic alarm(email notification and relay output)
