描述
Alcatel-Lucent OS9-GNI-C24E0产品详情
一、产品概述
Alcatel-Lucent OS9-GNI-C24E0是诺基亚（Nokia，原阿尔卡特朗讯）OS9系列中的一款千兆以太网接口模块，属于企业级或运营商级网络设备配件。该模块专为高密度、高性能网络设计，提供24个千兆以太网电口（RJ45），支持高速数据传输和灵活的网络扩展，适用于数据中心、企业园区网、运营商接入网等场景。
二、型号解析
OS9：表示产品所属系列，为诺基亚（原阿尔卡特朗讯）的高端模块化网络设备平台（如7750 SR系列路由器或OmniSwitch系列交换机）。
GNI：
G：通常代表“Gigabit”（千兆），表示接口速率。
NI：可能指“Network Interface”（网络接口）或特定接口类型标识。
C24E0：
C24：表示模块提供24个端口。
E0：可能为版本号或配置代码（如“E”代表电口，“0”表示标准配置）。
三、核心参数
接口规格：
端口数量：24个千兆以太网电口（RJ45）。
速率：支持10/100/1000 Mbps自适应，兼容旧有设备。
线缆类型：支持Cat5e及以上非屏蔽双绞线（UTP），最大传输距离100米。
性能指标：
背板带宽：依赖主设备（如OS9平台）的总带宽，单模块通常支持线速转发。
吞吐量：千兆端口全双工模式下可达2Gbps（发送+接收）。
MAC地址表：共享主设备MAC地址表容量（通常支持数万至数十万条目）。
功能特性：
自动协商：支持端口速率和双工模式自动协商，简化配置。
流量控制：支持IEEE 802.3x流控，防止网络拥塞。
VLAN支持：兼容802.1Q VLAN标记，实现逻辑隔离。
QoS：支持基于端口或802.1p/DSCP的优先级标记，保障关键业务流量。
节能设计：符合IEEE 802.3az（EEE）标准，低负载时降低功耗。
物理规格：
尺寸：标准模块化设计，适配OS9系列设备插槽（具体尺寸需参考设备手册）。
功耗：典型功耗约20-40W（依端口利用率而定）。
散热：依赖主设备散热系统，无独立风扇。
四、应用场景
企业园区网：
作为接入层交换机模块，连接办公终端、IP电话、无线AP等设备。
支持高密度端口需求，减少设备堆叠数量。
数据中心：
作为服务器接入模块，提供千兆到桌面的高速连接。
兼容虚拟化环境，支持VMware、Hyper-V等虚拟交换机集成。
运营商接入网：
用于FTTx（光纤到楼/户）场景，作为OLT（光线路终端）下联电口模块。
支持三网融合（语音、数据、视频）业务承载。
教育/医疗行业：
满足校园网、医院内部网络对高带宽和稳定性的要求。
五、优势特点
高密度端口：单模块集成24个千兆电口，节省机架空间。
灵活扩展：模块化设计支持按需扩容，降低初始投资成本。
兼容性强：适配诺基亚OS9系列多款设备，保护用户投资。
易于管理：通过主设备统一管理，支持SNMP、CLI、Web等多种管理方式。
可靠耐用：工业级设计，适应-20℃至+55℃工作环境（依主设备规格）。
Alcatel-Lucent OS9-GNI-C24E0 Product Details
I.Product Overview
The Alcatel-Lucent OS9-GNI-C24E0 is a Gigabit Ethernet interface module from Nokia(formerly Alcatel-Lucent)’s OS9 series.It’s an enterprise-or carrier-grade network equipment accessory.Designed for high-density,high-performance networks,this module provides 24 Gigabit Ethernet electrical ports(RJ45),supporting high-speed data transmission and flexible network expansion.It’s suitable for scenarios such as data centers,enterprise campus networks,and carrier access networks.
II.Model Explanation
OS9:Indicates the product series,which includes Nokia’s(formerly Alcatel-Lucent)high-end modular network equipment platform(such as the 7750 SR series routers or OmniSwitch series switches).
GNI:
G:Typically stands for”Gigabit,”indicating the interface speed.
NI:May refer to”Network Interface”or a specific interface type identifier.
C24E0:
C24:Indicates the module provides 24 ports.E0:This may be a version number or configuration code(e.g.,”E”represents an electrical port,”0″represents a standard configuration).
III.Core Parameters
Interface Specifications:
Number of Ports:24 Gigabit Ethernet electrical ports(RJ45).
Speed:Supports 10/100/1000 Mbps auto-negotiation,compatible with legacy devices.
Cable Type:Supports Cat5e and higher unshielded twisted pair(UTP)cables,with a maximum transmission distance of 100 meters.
Performance:
Backplane Bandwidth:Depends on the total bandwidth of the host device(such as the OS9 platform).A single module typically supports line-rate forwarding.
Throughput:Up to 2 Gbps(transmit+receive)in full-duplex mode on Gigabit ports.
MAC Address Table:Shares the MAC address table capacity of the host device(typically supporting tens to hundreds of thousands of entries).
Features:
Auto-negotiation:Supports auto-negotiation of port speed and duplex mode,simplifying configuration.
Flow Control:Supports IEEE 802.3x flow control to prevent network congestion.VLAN Support:Compatible with 802.1Q VLAN tagging for logical isolation.
QoS:Supports port-based or 802.1p/DSCP priority tagging to protect critical service traffic.
Energy-Saving Design:Compliant with IEEE 802.3az(EEE)standards,reducing power consumption during low loads.
Physical Specifications:
Dimensions:Standard modular design,compatible with OS9 series device slots(refer to the device manual for specific dimensions).
Power Consumption:Typical power consumption is approximately 20-40W(depending on port utilization).
Cooling:Relies on the main device cooling system;no independent fans are required.
IV.Application Scenarios
Enterprise Campus Network:
Serves as an access layer switch module,connecting office terminals,IP phones,wireless APs,and other devices.
Supports high-density port requirements,reducing the number of stacked devices.
Data Center:
Serves as a server access module,providing Gigabit-to-desktop high-speed connectivity.
Compatible with virtualization environments,supporting integration with virtual switches such as VMware and Hyper-V.Carrier Access Network:
For FTTx(Fiber to the Building/Home)scenarios,as a downlink electrical port module for the OLT(Optical Line Terminal).
Supports triple-network convergence(voice,data,and video)services.
Education/Healthcare:
Meets the high bandwidth and stability requirements of campus and hospital networks.
V.Advantages and Features
High Port Density:A single module integrates 24 Gigabit electrical ports,saving rack space.
Flexible Scalability:The modular design supports on-demand capacity expansion,reducing initial investment costs.
Strong Compatibility:Compatible with a wide range of Nokia OS9 devices,protecting user investment.
Easy Management:Centralized management via the master device supports multiple management methods,including SNMP,CLI,and Web.
Reliable and Durable:Industrial-grade design,suitable for operating environments from-20°C to+55°C(depending on the master device specifications).
