一、核心功能与定位
类型：工业控制主板/控制器模块，属于ALSTOM（现为通用电气能源部门）的冗余组态系统核心组件。
核心功能：
控制逻辑处理：执行燃气轮机、电力系统等工业设备的控制逻辑，监控运行状态。
多轴运动控制：支持8/24/64轴同步运动控制，兼容多轴插补、电子齿轮和电子凸轮等功能。
通信与扩展：通过gLink-II总线、以太网接口实现设备组网，支持HDMI、USB3.0、千兆网口等接口。
应用场景：
燃气轮机、蒸汽轮机、内燃机等能源动力系统的控制。
电力发电厂、变电站、电力网络的监控与调度。
工业自动化、过程控制、能源管理系统。
二、硬件配置与技术参数
主板规格
型号：EBC-GF81（Micro-ATX工业主板）。
处理器：Intel酷睿i7-4790（主频4.2GHz），支持双通道DDR3内存（最大8GB）。
存储：500GB硬盘（可选配其他容量）。
显卡：集成Intel HD核显，支持HDMI（4096×2304分辨率）和VGA（1920×1080分辨率）。
扩展模块
AIIS-3411P：4路PoE千兆以太网接口，支持摄像头兼容与电源管理。
AIIS-3411U：4路USB 3.0接口，专为多摄像头带宽优化设计。
AIIS-1882（可选）：4路光源控制输出（12VDC/1A），支持PWM调光和12路数字输入/16路数字输出。
运动控制能力
支持增量式/绝对值编码器，兼容GNC控制器同步控制。
提供电子齿轮、电子凸轮等复杂运动控制算法。
三、核心功能特点
高性能与可靠性
冗余组态设计，支持加密芯片和掉电保护（可选）。
工业级防护，适应恶劣环境（如宽温、振动、粉尘）。
安全与诊断
故障诊断与保护功能，实时监测设备状态并触发保护措施。
过载保护、短路保护等安全机制。
1.Core functions and positioning
Type:Industrial control motherboard/controller module,a core component of the redundant configuration system of ALSTOM(now General Electric Energy Department).
Core functions:
Control logic processing:Execute the control logic of industrial equipment such as gas turbines and power systems,and monitor the operating status.
Multi-axis motion control:supports 8/24/64 axis synchronous motion control,compatible with multi-axis interpolation,electronic gears and electronic cams.
Communication and expansion:Device networking is realized through gLink-II bus and Ethernet interface,supporting HDMI,USB3.0,Gigabit network port and other interfaces.
Application scenarios:
Control of energy power systems such as gas turbines,steam turbines,internal combustion engines.
Monitoring and scheduling of power plants,substations,and power networks.
Industrial automation,process control,energy management systems.
2.Hardware configuration and technical parameters
Motherboard specifications
Model:EBC-GF81(Micro-ATX Industrial Motherboard).
Processor:Intel Core i7-4790(main frequency 4.2GHz),supports dual-channel DDR3 memory(maximum 8GB).
Storage:500GB hard drive(optional with other capacity).
Graphics card:Integrated Intel HD core graphics,supports HDMI(4096×2304 resolution)and VGA(1920×1080 resolution).
Extended module
AIIS-3411P:4-channel PoE Gigabit Ethernet interface,supports camera compatibility and power management.
AIIS-3411U:4-channel USB 3.0 interface,specially designed for multi-camera bandwidth optimization.
AIIS-1882(optional):4-channel light source control output(12VDC/1A),supports PWM dimming and 12-channel digital input/16-channel digital output.
Movement control ability
Supports incremental/absolute encoder and is compatible with GNC controller synchronization control.
Provide complex motion control algorithms such as electronic gears and electronic cams.
3.Core functional characteristics
High performance and reliability
Redundant configuration design,support for encryption chip and power-down protection(optional).
Industrial-grade protection,adapted to harsh environments(such as wide temperature,vibration,dust).
Safety and diagnosis
Fault diagnosis and protection functions,real-time monitoring of equipment status and triggering protection measures.
Safety mechanisms such as overload protection and short circuit protection.
