描述
产品简要说明
ALSTOM MAE00-14是一款工业级模拟输入输出模块，专为高精度信号处理与控制设计，核心功能包括：
多通道信号交互：支持14路模拟输入（电压/电流信号）及多路模拟输出（标准电压/电流）
高分辨率转换：模数转换（ADC）与数模转换（DAC）分辨率高，确保信号处理精确性
工业环境适应性：坚固设计，抗干扰能力强，适用于复杂工业场景
产品详细说明
1.硬件架构与信号处理能力
输入通道设计：
支持电压信号（如0-10V、4-20mA）或电流信号（如0-20mA）输入
每通道独立隔离，减少信号串扰
输出通道特性：
可配置为电压输出（如0-10V）或电流输出（如4-20mA）
输出精度±0.1%（典型值）
2.工业级可靠性设计
抗干扰措施：
电磁屏蔽外壳，符合EN 50121-3-2标准
防雷击保护（浪涌抑制能力≥4kV）
环境适应性：
工作温度范围：-20℃至60℃
防护等级IP65（防尘防水）
3.灵活接口与兼容性
通信协议：
支持EtherCAT、Modbus RTU等工业协议
提供RS-485接口，波特率可配置（9600-115200 bps）
模块化扩展：
可与其他ALSTOM控制模块（如PLC、HMI）无缝集成
技术规格:ALSTOM MAE00-14
参数项规格描述
输入通道14路模拟输入（电压/电流可选）
输出通道多路模拟输出（电压/电流可配置）
分辨率ADC：16位；DAC：12位
接口类型EtherCAT、RS-485（Modbus RTU）
工作温度-20℃至60℃
防护等级IP65（防尘防水）
Product brief description
ALSTOM MAE00-14 is an industrial-grade analog input and output module designed for high-precision signal processing and control.The core functions include:
Multi-channel signal interaction:supports 14 analog inputs(voltage/current signals)and multiple analog outputs(standard voltage/current)
High resolution conversion:high resolution of analog to digital conversion(ADC)and digital to analog conversion(DAC)ensures accurate signal processing
Industrial environment adaptability:rugged design,strong anti-interference ability,suitable for complex industrial scenarios
Product details
1.Hardware architecture and signal processing capabilities
Input channel design:
Supports voltage signal(such as 0-10V,4-20mA)or current signal(such as 0-20mA)input
Independent isolation of each channel to reduce signal cross-chat
Output channel characteristics:
Can be configured as a voltage output(such as 0-10V)or a current output(such as 4-20mA)
Output accuracy±0.1%(typical)
2.Industrial-grade reliability design
Anti-interference measures:
Electromagnetic shielded housing,comply with EN 50121-3-2 standard
Lightning protection(surge suppression capability≥4kV)
Environmental adaptability:
Operating temperature range:-20℃to 60℃
Protection level IP65(dust-proof and waterproof)
3.Flexible interface and compatibility
Communication protocol:
Support industrial agreements such as EtherCAT,Modbus RTU,etc.
Provides RS-485 interface,baud rate configurable(9600-115200 bps)
Modular extension:
Can be seamlessly integrated with other ALSTOM control modules(such as PLC,HMI)
Technical Specifications:ALSTOM MAE00-14
Parameters Specification Description
Input channel 14 analog inputs(voltage/current optional)
Output channel Multi-channel analog output(voltage/current configurable)
Resolution ADC:16-bit;DAC:12-bit
Interface type EtherCAT,RS-485(Modbus RTU)
Operating temperature-20℃to 60℃
Protection level IP65(dust-proof and waterproof)
