描述
产品简要说明
ALSTOM VAGM22AF171G是阿尔斯通（ALSTOM）专为工业电机控制设计的高性能变频调速驱动器，核心特性包括：
功能定位：支持三相异步电机、永磁同步电机的变频调速与高效节能控制
工业兼容性：集成Modbus TCP、Profinet通信协议，支持工业物联网（IIoT）集成
环境适应性：IP55防护等级，适应-20°C～+50°C工作环境
扩展能力：支持DIN导轨安装，兼容ALSTOM工厂自动化系统生态
产品详细说明
1.硬件架构与核心功能
模块类型
功率单元：IGBT逆变模块，额定功率15kW，支持宽电压输入（380V AC±10%）
控制单元：
处理器：32位ARM Cortex-M7内核，实时控制频率1kHz
算法库：内置V/F控制、矢量控制、无传感器矢量控制模式
通信接口：双以太网端口（Profinet主站/从站）、RS485（Modbus RTU）
安全机制
过载保护：支持电机堵转、过热、过流三级保护
故障自诊断：实时监测IGBT温度、电容状态及通信中断
产品概述:ALSTOM VAGM22AF171G
作为工业电机驱动领域的核心设备，其核心价值体现在高效节能与智能化控制：
技术价值：
在风机/泵类负载中实现节能率30%～50%（相比传统工频控制）
支持多电机同步控制（最多8台电机集群）
行业适配：
制造业：生产线输送带、包装机械驱动
能源电力：水轮机辅助设备、油泵控制
轨道交通：列车通风系统、空调压缩机驱动
技术规格:ALSTOM VAGM22AF171G
参数项规格描述
额定功率15kW
输入电压380V AC±10%
效率等级IEC 60034-30-1 Class IE（满载效率≥96%）
防护等级IP55（防尘防喷水）
控制模式V/F控制、矢量控制（有/无传感器）
核心价值与性能亮点
1.多场景自适应控制
技术优势：
支持负载惯量自识别与动态转矩补偿
提供软启动/软停车曲线自定义功能
应用案例：某食品厂风机系统噪音降低15dB
2.工业级通信兼容性
技术优势：
Profinet实时通信延迟<1ms
支持OPC UA协议扩展（需固件升级）
价值体现：某汽车工厂实现设备群组远程集中监控
.Product brief description
ALSTOM VAGM22AF171G is a high-performance frequency conversion speed control driver designed by ALSTOM for industrial motor control.The core features include:
Functional positioning:Support frequency conversion speed regulation and efficient energy-saving control of three-phase asynchronous motors and permanent magnet synchronous motors
Industrial compatibility:Integrate Modbus TCP and Profinet communication protocols,support industrial Internet of Things(IIoT)integration
Environmental adaptability:IP55 protection level,adapted to-20°C~+50°C working environment
Extended capability:Support DIN rail installation,compatible with ALSTOM factory automation system ecosystem
Product details
1.Hardware architecture and core functions
Module Type
Power unit:IGBT inverter module,rated power 15kW,supports wide voltage input(380V AC±10%)
Control unit:
Processor:32-bit ARM Cortex-M7 core,real-time control frequency of 1kHz
Algorithm library:built-in V/F control,vector control,sensorless vector control mode
Communication interface:dual Ethernet ports(Profinet master/slave),RS485(Modbus RTU)
Security mechanism
Overload protection:Supports three-level protection for motor blocking,overheating and overcurrent
Fault self-diagnosis:Real-time monitoring of IGBT temperature,capacitance status and communication interruption
Product Overview:ALSTOM VAGM22AF171G
As the core equipment in the field of industrial motor drive,its core value is reflected in efficient energy saving and intelligent control:
Technical value:
Achieve energy saving rate of 30%to 50%in fan/pump loads(compared with traditional power frequency control)
Supports multi-motor synchronous control(up to 8 motor clusters)
Industry adaptation:
Manufacturing industry:production line conveyor belt,packaging machinery drive
Energy and electricity:turbine auxiliary equipment,oil pump control
Rail Transit:Train ventilation system,air conditioning compressor drive
Technical Specifications:ALSTOM VAGM22AF171G
Parameters Specification Description
Rated power 15kW
Input voltage 380V AC±10%
Efficiency Level IEC 60034-30-1 Class IE(full load efficiency≥96%)
Protection level IP55(dust-proof and water-spray-proof)
Control mode V/F control,vector control(with/without sensor)
Core Valuesand Performance Highlights
1.Multi-scene adaptive control
Technical Advantages:
Supports load inertia self-identification and dynamic torque compensation
Provides soft start/soft parking curve customization function
Application case:The noise of the fan system of a food factory is reduced by 15dB
2.Industrial-grade communication compatibility
Technical Advantages:
Profinet real-time communication delay<1ms
Supports OPC UA protocol extension(requires firmware upgrade)
Value manifestation:A certain automobile factory realizes remote centralized monitoring of equipment groups
