描述
安立无线通信分析仪(MT880X系列)的一般特性
多制式测试：它们旨在测试各种全球无线通信系统。旧型号通常支持以下标准：
IS-95、CDMA2000 1X
GSM/DCS1800/PCS1900、GPRS、HSCSD
IS-136A
PDC、PHS
该系列的后续型号已发展到支持3G、4G LTE以及现在的5G技术。
集成测试仪器：这些设备将多种测试功能集成到一个单元中，其中包括：
信号发生器：输出射频信号，用于测试接收机灵敏度和其他与输入相关的测量。
射频分析仪：用于测量传输特性，例如频率、功率、调制精度（例如相位误差）、突发波的上升/下降特性以及邻道功率。
音频分析仪：用于测量音频电平、频率和失真度。
功率计：内置功率计，可进行精确的功率测量。
频谱分析仪（通常为选配）：用于分析频谱，可用于测量杂散发射和常规故障排除。
频率范围：通常覆盖较宽的频率范围，例如，老款型号为300 kHz至3 GHz，而现代型号则扩展到更高的5G频率（Sub-6 GHz和毫米波）。
呼叫处理功能：能够与被测设备（例如手机）建立并维持通话，从而进行全面的测试。
测量精度和速度：专为快速准确的测量而设计，这对于研发和大批量生产环境都至关重要。
自动化接口：配备GPIB(IEEE-488)和RS-232C等标准接口，可用于远程控制和集成到自动化测试系统中。以太网和USB在较新的型号中较为常见。
用户界面：配备显示屏（例如彩色TFT-LCD），用于显示测量结果。
潜在应用
安立无线电通信分析仪（包括MT8803G0等潜在型号）在以下领域不可或缺：
无线设备制造：用于智能手机、平板电脑和其他无线通信设备的生产线测试。
研发和设计验证：用于开发和验证新型无线通信模块和芯片组。
安装和维护：用于基站和无线网络基础设施的故障排除和维护。
质量保证：确保设备符合行业标准和规范。
General Features of Anritsu Radio Communication Analyzers(MT880X series)
Multi-Format Testing:They are designed to test a wide range of global radio communication systems.Older models often supported standards like:
IS-95,CDMA2000 1X
GSM/DCS1800/PCS1900,GPRS,HSCSD
IS-136A
PDC,PHS
Later models in the series evolved to support 3G,4G LTE,and now 5G technologies.
Integrated Test Instruments:These devices integrate multiple test functions into a single unit,which can include:
Signal Generator:To output RF signals for testing receiver sensitivity and other input-related measurements.
RF Analyzer:For measuring transmission characteristics like frequency,power,modulation accuracy(e.g.,phase error),rise/fall characteristics of burst waves,and adjacent channel power.
Audio Analyzer:For AF level,frequency,and distortion measurements.
Power Meter:Built-in for accurate power measurements.
Spectrum Analyzer(often optional):To analyze the frequency spectrum,useful for measuring spurious emissions and general troubleshooting.
Frequency Range:Typically cover a broad frequency range,for example,from 300 kHz up to 3 GHz(for older models),with modern versions extending into much higher frequencies for 5G(Sub-6 GHz and mmWave).
Call Processing Functionality:Ability to establish and maintain calls with devices under test(e.g.,mobile phones)for comprehensive testing.
Measurement Accuracy and Speed:Designed for fast and accurate measurements,crucial for both R&D and high-volume manufacturing environments.
Automation Interfaces:Equipped with standard interfaces like GPIB(IEEE-488)and RS-232C for remote control and integration into automated test systems.Ethernet and USB are common in newer models.
User Interface:Features a display(e.g.,color TFT-LCD)for displaying measurement results.
Likely Applications
Anritsu Radio Communication Analyzers,including potential variants like the MT8803G0,are indispensable in:
Wireless Device Manufacturing:For production-line testing of smartphones,tablets,and other wireless communication devices.
R&D and Design Verification:For developing and verifying new wireless communication modules and chipsets.
Installation&Maintenance:For troubleshooting and maintaining base stations and wireless network infrastructure.
Quality Assurance:Ensuring devices meet industry standards and specifications.
