描述
APC GES501W48V01800产品详情
一、产品概述
APC GES501W48V01800是施耐德电气（Schneider Electric）旗下APC品牌推出的一款48V直流电源系统，专为通信基站、数据中心、工业控制等场景设计。该产品属于GES（Global Energy Solutions）系列，提供高效、可靠的直流供电解决方案，支持关键负载的持续运行，并具备智能监控和远程管理功能。
二、型号解析
GES：表示产品系列，属于APC的全球能源解决方案（Global Energy Solutions）产品线，专注于通信和工业电源。
501W：
501：可能为产品子系列或功率等级标识（如500W级别）。
W：代表“Watt”（瓦特），表示电源的输出功率或设计容量。
48V：明确输出电压为48V直流电，符合通信行业标准（如ETSI、IEEE）。
01800：
01：可能为版本号或配置代码（如“01”表示基础版）。
800：可能指电池容量（如800Ah）或模块编号（需结合技术手册确认），但更可能是型号后缀，用于区分具体配置。
注：部分资料显示该型号可能对应48V 500W直流电源模块，实际参数需以官方文档为准。
三、核心参数
输入参数：
输入电压范围：通常支持85-264VAC（单相）或180-300VDC（依型号而定），适应不同电网条件。
输入频率：47-63Hz（交流输入时）。
功率因数：≥0.99（符合IEC 61000-3-2标准），减少无功功率损耗。
输出参数：
输出电压：48VDC±1%（稳压精度高，适合敏感负载）。
额定功率：500W（或501W，依型号而定），支持连续负载。
输出电流：约10.4A（500W/48V），峰值电流可能更高（需确认过载能力）。
效率：≥92%（典型负载下），降低能耗和发热。
电池管理：
电池类型：支持阀控式铅酸电池（VRLA）或锂电池（需选配适配模块）。
充电功能：内置三段式充电（恒流-恒压-浮充），延长电池寿命。
电池容量：若型号中“800”指电池容量，可能支持800Ah电池组（需验证）。
保护功能：
输入保护：过压、欠压、浪涌抑制，防止电网波动损坏设备。
输出保护：短路、过载、过温保护，自动切断输出以保障安全。
电池保护：反接、深放电保护，避免电池误操作导致损坏。
监控与管理：
本地监控：LED指示灯显示电源状态（运行、故障、充电）。
远程管理：支持SNMP、Modbus、Web界面或APC PowerChute软件，实现实时监控和配置。
报警功能：通过干接点、邮件或短信发送故障通知（需连接网络管理设备）。
四、应用场景
通信基站：
为基站设备（如BBU、RRU、传输设备）提供稳定48V直流电。
结合电池组实现市电中断时的备用供电（支持数小时运行）。
数据中心：
作为分布式电源系统，为服务器机柜或网络设备供电。
与UPS系统配合，提升供电冗余度。
工业控制：
为PLC、传感器、执行器等工业设备提供可靠直流电源。
适应工厂恶劣环境（防尘、防潮、宽温）。
交通领域：
用于轨道交通信号系统、高速公路监控设备供电。
支持太阳能或风能混合供电场景。
APC GES501W48V01800 Product Details
I.Product Overview
The APC GES501W48V01800 is a 48V DC power supply system from APC,a Schneider Electric brand.It is designed for applications such as communication base stations,data centers,and industrial control systems.This product belongs to the GES(Global Energy Solutions)series,providing efficient and reliable DC power solutions that support the continuous operation of critical loads and feature intelligent monitoring and remote management capabilities.
II.Model Explanation
GES:Indicates the product series,part of APC’s Global Energy Solutions product line,which specializes in communications and industrial power supplies.
501W:
501:This may indicate a product sub-series or power rating(e.g.,500W).
W:Stands for”Watt,”indicating the power supply’s output power or design capacity.
48V:Specifies the output voltage as 48V DC,compliant with communications industry standards(e.g.,ETSI and IEEE).01800:
01:May be a version number or configuration code(e.g.,”01″indicates the basic version).
800:May refer to the battery capacity(e.g.,800Ah)or module number(please consult the technical manual for confirmation),but is more likely a model suffix used to distinguish specific configurations.
Note:Some sources indicate this model number corresponds to a 48V 500W DC power supply module.Please refer to official documentation for actual specifications.
III.Core Parameters
Input Parameters:
Input Voltage Range:Typically supports 85-264VAC(single-phase)or 180-300VDC(depending on the model),adapting to different grid conditions.
Input Frequency:47-63Hz(AC input).
Power Factor:≥0.99(compliant with IEC 61000-3-2 standard),reducing reactive power loss.
Output Parameters:
Output Voltage:48VDC±1%(high voltage regulation accuracy,suitable for sensitive loads).Rated Power:500W(or 501W,depending on the model),supporting continuous loads.
Output Current:Approximately 10.4A(500W/48V),peak current may be higher(overload capability requires verification).
Efficiency:≥92%(under typical load),reducing energy consumption and heat generation.
Battery Management:
Battery Type:Supports valve-regulated lead-acid(VRLA)or lithium batteries(requires an optional adapter module).
Charging:Built-in three-stage charging(constant current,constant voltage,and float charge)extends battery life.
Battery Capacity:If”800″in the model number refers to battery capacity,it may support an 800Ah battery pack(subject to verification).
Protection Features:
Input Protection:Overvoltage,undervoltage,and surge suppression prevent damage to the device from grid fluctuations.
Output Protection:Short-circuit,overload,and overtemperature protection,with automatic output cutoff for safety.
Battery Protection:Reverse polarity and deep discharge protection prevent battery damage from misuse.Monitoring and Management:
Local Monitoring:LED indicators display power status(operating,fault,charging).
Remote Management:Supports SNMP,Modbus,web interface,or APC PowerChute software for real-time monitoring and configuration.
Alarm Function:Fault notifications are sent via dry contacts,email,or SMS(requires connection to a network management device).
IV.Application Scenarios
Communication Base Station:
Provides stable 48V DC power to base station equipment(such as BBU,RRU,and transmission equipment).
Combined with a battery pack,it provides backup power during utility power outages(supporting several hours of operation).
Data Center:
Serves as a distributed power system to power server cabinets or network equipment.
Works with a UPS system to enhance power redundancy.
Industrial Control:
Provides reliable DC power to industrial equipment such as PLCs,sensors,and actuators.
Adapts to harsh factory environments(dustproof,moisture-proof,and wide temperature range).
Transportation:
Powers rail transit signal systems and highway monitoring equipment.
Supports hybrid solar and wind power supply scenarios.
