描述
BECKWITH M-3425A是Beckwith Electric Company（美国知名电力保护与控制设备制造商）生产的一款高性能发电机保护继电器，专为同步发电机、涡轮发电机及水力发电机设计，提供全面的电气故障检测与保护功能。以下是基于官方资料及行业经验的详细整理：
一、产品概述
品牌与定位
品牌：Beckwith Electric（成立于1965年，专注于电力系统保护、监控与自动化）。
定位：高端发电机保护解决方案，适用于电力发电、工业驱动及可再生能源领域。
型号含义
M-3425A：
M：模块化设计（Modular），支持灵活配置。
3425：产品系列代码，指示功能类别（发电机保护）。
A：版本号（如硬件升级或功能扩展）。
二、核心功能与应用
主要保护功能
差动保护：快速检测发电机定子绕组内部故障（如相间短路）。
过流保护：防范过载、短路及接地故障。
电压保护：监测过压、欠压及电压不平衡。
频率保护：防止频率异常（如超频/低频运行）。
失步保护：检测发电机与电网失步，避免设备损坏。
逆功率保护：防止发电机变为电动机模式运行。
热过载保护：基于IEC 60034标准，跟踪电机发热模型。
典型应用场景
火力发电厂：保护汽轮发电机。
水力发电站：保护水轮发电机。
可再生能源：风电、光伏配套储能发电机保护。
工业驱动：大型电机驱动系统（如压缩机、泵）。
The BECKWITH M-3425A is a high-performance generator protection relay manufactured by Beckwith Electric Company(a renowned American manufacturer of power protection and control equipment).Designed for synchronous generators,turbine generators,and hydroelectric generators,it provides comprehensive electrical fault detection and protection.The following is a detailed summary based on official documentation and industry experience:
I.Product Overview
Brand and Positioning
Brand:Beckwith Electric(founded in 1965,specializing in power system protection,monitoring,and automation).
Positioning:A high-end generator protection solution suitable for power generation,industrial drives,and renewable energy.
Model Meaning
M-3425A:
M:Modular design,allowing for flexible configuration.
3425:Product series code,indicating the functional category(generator protection).
A:Version number(e.g.,for hardware upgrades or function expansions).
II.Core Functions and Applications
Main Protection Functions
Differential protection:Rapidly detects internal faults in the generator stator winding(such as phase-to-phase short circuits).
Overcurrent protection:Protects against overload,short circuit,and ground faults.Voltage protection:Monitors overvoltage,undervoltage,and voltage imbalance.
Frequency protection:Prevents frequency anomalies(such as overfrequency or underfrequency operation).
Out-of-step protection:Detects loss of synchronism between the generator and the grid to prevent equipment damage.
Reverse power protection:Prevents the generator from operating in motor mode.
Thermal overload protection:Based on the IEC 60034 standard,it tracks the motor’s thermal model.
Typical application scenarios:
Thermal power plants:Protect steam turbine generators.
Hydroelectric power plants:Protect hydroelectric generators.
Renewable energy:Protect wind power and photovoltaic generators with energy storage.
Industrial drives:Protect large motor drive systems(such as compressors and pumps).
