产品概述
BENTLY 330980-51-00是BENTLY NEVADA 3300XL系列前置器的核心组件，专为工业振动监测系统设计，支持高精度动态信号处理与机械保护功能。其核心功能包括振动、位移、转速等参数的实时监测，广泛应用于电力、冶金、石化等行业的旋转机械保护系统中。
技术参数
物理规格
安装方式：支持DIN导轨安装和传统面板安装，兼容高密度机架布局。
尺寸：未明确具体尺寸，但符合工业标准模块化安装要求。
防护等级：IP30（室内环境适用）。
电气特性
工作电压：24 V DC或115/230 V AC（需确认具体型号规格）。
信号处理：支持电涡流传感器系统，通过前置器将探头感应的机械振动转换为电信号。
电气长度匹配：前置器、探头与延伸电缆的总电气长度需严格一致，以确保测量精度。
环境适应性
工作温度：-40°C至+70°C（标准型），高温型可达260°C。
抗干扰能力：高度抗射频干扰（RFI/EMI），适用于复杂电磁环境。
核心功能特点
冗余与可靠性
支持冗余FCI模件安装，主备模式自动切换，提升系统可用性。
内置自诊断功能，实时监测模块状态并触发报警。
信号处理能力
振动监测：支持宽带和窄带滤波器，实现振幅与相位同步分析。
转速测量：兼容键相信号输入，支持动态转速跟踪。
位移监测：用于轴向位移、胀差等关键参数的实时监测。
安装与兼容性
SpringLoc端子：无需工具即可紧固，防止松动。
ClickLoc镀金铜接头：防腐蚀设计，支持快速插拔。
兼容性：与3300XL系列探头、延伸电缆及3500监测系统兼容，可扩展至大型工业控制系统。
安全与维护
隔离设计：安装底座提供电气隔离，无需额外隔离板。
温度范围扩展：支持高温型组件（ETR），适用于极端环境。
应用场景
电力行业
汽轮机、发电机的振动与位移监测，预防机械故障。
石化与冶金
压缩机、泵、风机的动态性能分析与保护。
旋转机械保护
轴承、齿轮箱的振动异常检测与报警。
工业自动化
作为DCS/PLC系统的传感器接口，集成至大型过程控制网络。
