描述
BENTLY 3500-91M 190782-01是一款通信网关模块，属于本特利内华达（Bently Nevada）3500系列在线监测与保护系统，以下为其产品详情：
一、核心功能
数据通信与协议支持
模块专为3500系列机架提供数据通信功能，支持EGD（以太网全局数据）协议，兼容EGD V2.01和以太网UDP/IP协议，实现高效数据传输。
支持Modbus TCP/IP、BACnet等工业通信协议，可与不同厂家和类型的设备进行数据交换。
数据采集与传输
实时采集旋转设备的监测数据（如振动、温度、压力等），并通过网络接口传输至DCS（分布式控制系统）或SCADA系统，支持生产者和消费者数据交换，涵盖机架状态、报警复位、报警抑制等功能。
远程监控与诊断
支持远程访问，允许操作人员通过网络实时监控设备运行状态，进行远程诊断和控制，适用于工业自动化、发电厂设备监控、石油天然气旋转设备监测等场景。
二、技术特性
通信接口与网络
提供10BASE-T和100BASE-TX（双绞线）网络连接，符合IEEE 802.3标准，支持以太网通信。
系统兼容性与集成
可与支持EGD协议的控制系统（如GE Mark VIe）集成，实现状态监控和数据分析。
采用模块化设计，主模块占用3500机架前部一个全高插槽，I/O模块安装于机架后部对应插槽，便于扩展和维护。
状态指示与功耗
配备OK指示灯（显示模块运行状态）和TX/RX指示灯（指示网络通信情况），典型功率为7.4W。
三、应用领域
电力行业
用于发电厂设备监控，通过实时数据传输和远程管理功能，提高发电设备的运行效率和可靠性。
石油天然气行业
实时监测旋转设备健康状况，预防设备故障，支持石油天然气生产流程的连续性。
工业自动化
连接SCADA/DCS系统，实现远程监控和数据管理，优化工业生产流程，减少人工干预
BENTLY 3500-91M 190782-01 is a communication gateway module,which belongs to the Bently Nevada 3500 series online monitoring and protection system.The following are its product details:
1.Core functions
Data communication and protocol support
The module is designed to provide data communication functions for the 3500 series racks,supports EGD(Ethernet Global Data)protocol,and is compatible with EGD V2.01 and Ethernet UDP/IP protocol to achieve efficient data transmission.
Supports industrial communication protocols such as Modbus TCP/IP and BACnet,and can exchange data with equipment of different manufacturers and types.
Data acquisition and transmission
Real-time collection of monitoring data of rotating equipment(such as vibration,temperature,pressure,etc.),and transmits it to DCS(distributed control system)or SCADA system through the network interface,supports producer and consumer data exchange,and covers functions such as rack status,alarm reset,and alarm suppression.
Remote monitoring and diagnosis
Supports remote access,allowing operators to monitor the operating status of equipment in real time through the network,perform remote diagnosis and control,and is suitable for scenarios such as industrial automation,power plant equipment monitoring,and oil and gas rotating equipment monitoring.
2.Technical characteristics
Communication interface and network
Provides 10BASE-T and 100BASE-TX(twisted pair)network connections,complies with IEEE 802.3 standards,and supports Ethernet communication.
System compatibility and integration
Can be integrated with control systems that support the EGD protocol(such as GE Mark VIe)to achieve status monitoring and data analysis.
Adopting a modular design,the main module occupies a full-height slot at the front of the 3500 rack,and the I/O module is installed in the corresponding slot at the rear of the rack for easy expansion and maintenance.
Status indication and power consumption
Equipped with an OK indicator(displaying the module operating status)and a TX/RX indicator(indicating network communication status),the typical power is 7.4W.
3.Application field
Power industry
Used for power plant equipment monitoring,through real-time data transmission and remote management functions,to improve the operating efficiency and reliability of power generation equipment.
Oil and gas industry
Real-time monitoring of the health of rotating equipment,prevention of equipment failures,and support for the continuity of oil and gas production processes.
Industrial automation
Connect to SCADA/DCS systems to achieve remote monitoring and data management,optimize industrial production processes,and reduce manual intervention
