描述
1.产品概述
3500-92 136180-01是3500系列框架的通信网关模块，采用双冗余以太网接口设计，支持Modbus TCP、OPC UA、EtherNet/IP等工业协议，可同时连接多台3500框架与上位机软件/控制系统，实现高速数据交换与集中管理。模块内置ARM Cortex-A9处理器与1GB DDR3内存，具备实时数据处理、协议转换与安全加密能力，符合IEC 61850（变电站通信标准）和ISA-95（企业-控制系统集成标准），广泛应用于电力、石油天然气、化工、冶金等行业的关键设备远程监控与数字化运维。
核心定位
应用场景：
电力行业：汽轮机、发电机的3500监测框架与DCS/SCADA系统的数据互通，实现振动、位移、温度等参数的集中显示与联锁保护。
石油天然气：压缩机站、海上平台的多台3500框架通过3500-92汇总数据至中控室，支持远程诊断与故障预判。
化工行业：反应釜、离心机的3500监测数据与MES（制造执行系统）对接，优化生产流程与设备利用率。
冶金行业：高炉风机、轧机主传动的3500框架通过3500-92连接5G工业网关，实现边缘计算与云端分析。
技术优势：
高带宽通信：双千兆以太网接口，单端口最大吞吐量1Gbps，满足多框架、高采样率数据（如10kHz振动）的实时传输需求。
协议兼容性：支持Modbus TCP（主/从模式）、OPC UA（服务器/客户端）、EtherNet/IP（适配器/扫描器），可适配西门子、施耐德、罗克韦尔等主流PLC系统。
冗余设计：双网口独立供电，支持链路聚合（LACP）或主备切换，确保通信连续性（故障恢复时间<50ms）。
安全加密：支持TLS 1.2/1.3、AES-256加密，防止数据泄露与非法访问，符合IEC 62443（工业控制系统安全标准）。
2.技术规格与性能参数
2.1基础参数
参数规格
型号3500-92 136180-01
制造商Bently Nevada（Baker Hughes旗下）
产品系列Bently 3500系列机械保护与状态监测系统
模块类型通信网关模块（支持数据采集、协议转换与远程传输）
接口数量2个千兆以太网接口（RJ45），支持M12工业级连接器（可选）
协议支持-Modbus TCP：主/从模式，支持功能码01-06、15-16
-OPC UA：服务器/客户端，支持数据访问、报警与条件、历史访问
-EtherNet/IP：适配器/扫描器，支持显式消息与I/O连接
-自定义协议：可通过SDK开发适配特殊设备
数据处理能力-最大连接框架数：32台（通过背板总线）
-每秒处理数据点数：>50,000点（Modbus TCP）
-历史数据缓存：内置4GB Flash，可存储7天原始数据（采样率100ms时）
1.Product Overview
3500-92 136180-01 is a communication gateway module for the 3500 series frame.It adopts a dual redundant Ethernet interface design and supports industrial protocols such as Modbus TCP,OPC UA,and EtherNet/IP.It can simultaneously connect multiple 3500 frames and host computer software/control systems to achieve high-speed data exchange and centralized management.The module has a built-in ARM Cortex-A9 processor and 1GB DDR3 memory,and has real-time data processing,protocol conversion and security encryption capabilities.It complies with IEC 61850(substation communication standard)and ISA-95(enterprise-control system integration standard),and is widely used in remote monitoring and digital operation and maintenance of key equipment in industries such as power,oil and gas,chemical industry,and metallurgy.
Core positioning
Application scenarios:
Electric power industry:Data intercommunication between the 3500 monitoring framework of steam turbines and generators and the DCS/SCADA system to realize centralized display and interlocking protection of parameters such as vibration,displacement,and temperature.
Oil and gas:Multiple 3500 frameworks of compressor stations and offshore platforms aggregate data to the central control room through 3500-92,supporting remote diagnosis and fault prediction.
Chemical industry:The 3500 monitoring data of reactors and centrifuges is connected to MES(manufacturing execution system)to optimize production processes and equipment utilization.
Metallurgical industry:The 3500 framework of blast furnace fans and rolling mill main drives is connected to the 5G industrial gateway through 3500-92 to realize edge computing and cloud analysis.
Technical advantages:
High-bandwidth communication:Dual Gigabit Ethernet interfaces,single-port maximum throughput of 1Gbps,meeting the real-time transmission requirements of multi-frame,high-sampling rate data(such as 10kHz vibration).
Protocol compatibility:Supports Modbus TCP(master/slave mode),OPC UA(server/client),EtherNet/IP(adapter/scanner),and can be adapted to mainstream PLC systems such as Siemens,Schneider,and Rockwell.
Redundant design:Dual network ports are independently powered,supporting link aggregation(LACP)or master-slave switching to ensure communication continuity(fault recovery time<50ms).
Secure encryption:Supports TLS 1.2/1.3,AES-256 encryption to prevent data leakage and illegal access,in line with IEC 62443(industrial control system security standard).
2.Technical specifications and performance parameters
2.1 Basic parameters
Parameters Specifications
Model 3500-92 136180-01
Manufacturer Bently Nevada(Baker Hughes)
Product series Bently 3500 series machinery protection and condition monitoring system
Module type Communication gateway module(supports data acquisition,protocol conversion and remote transmission)
Number of interfaces 2 Gigabit Ethernet interfaces(RJ45),support M12 industrial connector(optional)
Protocol support-Modbus TCP:master/slave mode,support function codes 01-06,15-16
-OPC UA:server/client,support data access,alarms and conditions,historical access
-EtherNet/IP:adapter/scanner,support explicit messages and I/O connections
-Custom protocols:can be developed through SDK to adapt to special devices
Data processing capacity-Maximum number of connection frames:32 units(via backplane bus)
-Data points processed per second:>50,000 points(Modbus TCP)
-Historical data cache:Built-in 4GB Flash,can store 7 days of raw data(at a sampling rate of 100ms)
