描述
BENTLY 3500/72M-01-00 140734-08是本特利内华达（Bently Nevada）公司生产的一款连杆位置监测器，属于3500系列，主要用于监测往复式压缩机中往复杆的位置。具体详情如下：
电源：通常由3500机架电源供电。
输入：4个传感器输入，可支持2线和3线加速度计、速度传感器或近程传感器。
温度输入：4个温度输入，支持E、J、K和T型热电偶，以及双线或三线RTD。
输出：6个继电器输出、4个4-20mA记录器输出和1个专用缓冲输出。
通信接口：支持Modbus RTU，也可通过以太网和软件可配置的RS232/485串行端口进行Modbus通信，还支持Ethernet/IP和Profinet等协议。
工作温度范围：-40°C至+70°C。
尺寸：约241.3mm×24.4mm×241.8mm。
重量：约0.91kg。
产品特点：可精确测量杆位置，能早期检测潜在问题；用户可设置可定制的报警阈值；符合API 618标准；可通过3500机架配置软件对每个通道进行编程，实现杆位置测量、杆下落测量、超压缩测量等功能。
The BENTLY 3500/72M-01-00 140734-08 is a connecting rod position monitor manufactured by Bently Nevada.It belongs to the 3500 series and is primarily used to monitor the position of reciprocating rods in reciprocating compressors.Specific details are as follows:
Power Supply:Typically powered by the 3500 rack power supply.
Inputs:Four sensor inputs supporting 2-wire and 3-wire accelerometers,velocity sensors,or proximity sensors.
Temperature Inputs:Four temperature inputs supporting E,J,K,and T-type thermocouples,as well as 2-wire and 3-wire RTDs.
Outputs:Six relay outputs,four 4-20mA recorder outputs,and one dedicated buffered output.
Communication Interfaces:Supports Modbus RTU,Modbus communication via Ethernet and a software-configurable RS232/485 serial port.Protocols such as Ethernet/IP and Profinet are also supported.Operating temperature range:-40°C to+70°C.
Dimensions:Approximately 241.3mm×24.4mm×241.8mm.
Weight:Approximately 0.91kg.
Features:Accurately measures rod position,enabling early detection of potential problems;user-configurable alarm thresholds;API 618 compliant;each channel can be programmed using 3500 Rack Configuration Software to measure rod position,rod drop,over-compression,and other functions.
